Help CenterGas Oil Tanker,gas Delivery Truck
US$ 10,000 - 40,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Storage:
LPG
Drive Wheel:
4x2
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Gas Mini Truck,gas Oil TankerUS$ 10,000 - 40,000MOQ: 1 Unit -
3 Axles Lpg Tank Trailer, 3 Axle Lpg Propane Tank Semi Trailer, 40ft Lpg ContainerUS$ 10,000 - 40,000MOQ: 1 Unit
-
40ft Lpg Container,3 Axles Lpg Tank Trailer,US$ 10,000 - 40,000MOQ: 1 Unit
-
3 Axle Lpg Propane Tank Semi Trailer,40ft Lpg ContainerUS$ 10,000 - 40,000MOQ: 1 Unit
-
Gas Oil Tanker,gas Propane Cylinder,gas Stations TankUS$ 10,000 - 40,000MOQ: 1 Unit
Condition
New
Storage
LPG
Drive Wheel
4x2
Horsepower
251 - 350hp
Transmission Type
Manual
Fuel Type
Gasoline
Tank Volume
5001 - 10000L
Engine Capacity
3856cc
Dimensions (L x W x H) (mm)
5900x2045x2600
Brand Name
CLW
Place of Origin
Hubei, China
Model Number
CLW
Gross Vehicle Weight
5000
LPG,liquid pressure gas,which is made from oil.The main gas is propane,Isobutane.
Currently our company produce the lpg tank, lpg tank trailer,lpg tank truck to loading and transporting.
The LPG tank volume from 5~120 m3 for above ground, 5~100 m3 for underground.
The LPG tank trailer volume from 30~60 m3 with two axles or three axles.
The LPG tank truck with the volume from 5~35 m3.
Currently our company produce the lpg tank, lpg tank trailer,lpg tank truck to loading and transporting.
The LPG tank volume from 5~120 m3 for above ground, 5~100 m3 for underground.
The LPG tank trailer volume from 30~60 m3 with two axles or three axles.
The LPG tank truck with the volume from 5~35 m3.
Product Description
gas delivery truck,gas mini truck,gas oil tanker
Main Specification
gas delivery truck,gas mini truck,gas oil tanker
Item |
Unit |
Description |
|||||||
Model |
CLW5070GYQ |
||||||||
Dimension |
mm |
5900×2045×2600 |
|||||||
Tank Dimension |
mm |
3059×1620 / 5.5 cubic meter |
|||||||
Curb Weight |
kg |
4990 |
|||||||
Wheel Base |
mm |
3300 |
|||||||
F/R track base |
mm |
1586/1530 |
|||||||
F/R Axle-Load |
Kg |
3200/4295 |
|||||||
Approach/Departure angle |
. |
18/12 |
|||||||
Traction system |
4x2 |
Tire Specification/Number |
7.00-16 / 6 Units |
||||||
Max speed |
90 km/h |
Number of axles |
2 |
||||||
Engine model |
CY4102-C3F |
Emission/kw |
3856ml/70KW, 95Hp |
||||||
Diesel, 4 Cylinders, Diesel, Direct-line, Turbocharge and aftercooling | |||||||||
Engine Manufacturer |
Dong Feng Chao Yang Engine Co.,Ltd |
||||||||
Steering |
Powering, Dong Feng |
Transmission |
5 speed with over drive, 5F&1R |
||||||
Cab passenger |
3 |
Electric System |
24V |
||||||
Dirve system |
left hand or Right hand driven. |
||||||||
Air Condition |
Yes |
CD , Radio, Mp3 |
|||||||
Tank Design | |||||||||
Load Substance: |
Oil Gas (propane) |
Designed Pressure: |
1.77Mpa |
Designed TEMP: |
50 °C |
||||
Load parameter: |
0.42T/m 3 |
Material: |
Q345R , 16MnIII |
||||||
Remark: |
Equipment with Safety Valve, Liquid gage, Pressure gage, Temperature gage, Urgent cut off valve, Valve box, Fire extinguisher, plastic pipe of staticproof, Well-secured fenders and mudguards, Tire well-secured, fenders and mudguards. |
||||||||
More photos showing.
gas delivery truck,gas mini truck,gas oil tanker
Related product show
gas delivery truck,gas mini truck,gas oil tanker
Materials rolled into tank, Q345R, Q370R, 16MnIII,
Water Pressure testing.
Tank heating testing room.
X-ray testing for the tank side cover welding.
-----------------------------------------------------------
Manufacturer Standard: GB150, China. which is stricter than ASME standard.
We also could produce the product according the ASME standard.
-----------------------------------------------------------
Certificate: CCC, ISO, BV, SGS, which is showing on our website.
-----------------------------------------------------------
