It owns the features of portability, integration, miniaturization and so on, offering mobile, steady and excellent AC power for different kinds of electronic devices which are outdoor and far away from electricity grid. It is widely used in the rescue and relief work, field working, emergency communications, scientific investigation and adventure travel.w
♦Adopt portable rod, easy to move, simple to operate
♦ Small in size, light in weight and hign in efficiency.
♦ Advanced dual CPU single intelligent controling technology.
♦ Sine wave output to offer the best electricity consuming environment for load.
♦ All-round protection function, including overload, short circuit, undervoltage and over temperature
♦ Use new LiFePO4 battery, high performance.
♦ Intelligent battery management technology, long service life
♦ With DC 24V output interface and dual USB output interface
♦ Support large charging current to shorten the charging timenic devices
Input specification | |
Rated input voltage |
220V AC / 50 Hz one phase |
Output specification | |
AC output voltage |
AC 220V ±15V |
AC output power factor |
0.85 |
AC output power |
500/425(VA/W) |
AC output frequency |
50±5 Hz |
AC total harmonic distoration |
THD ≤5% |
AC output waveform |
Sinusoidal wave |
Startup mode |
Soft startup |
Protection |
Overload, short circuit, undervoltage and over temperature |
DC output voltage |
DC+5V |
DC output power |
10W |
Battery | |
Battery type |
LiFePO4 |
DC rated voltage |
12V DC |
Capacity |
100Ah |
Total power |
1280Wh |
Charging current |
10A±1A |
Others | |
Dimension(L*W*H) |
430 * 345 * 430(without the bar) |
Weight |
28±1 kg |
Operating temperature |
-10~50°C |
Operating Humidity |
20%~90%RH (without condensation) |
Storage temperature |
-15~55°C |
Warranty |
12 months |
FRONT VIEW
BACK VIEW
Power indicator: four red LED lights, from left to right 25%, 50%, 75%, 100%
Protection cover: half transparent plastic cover to protect the operational switch and output socket.
Switch: to change the product’s working status of charge, off and power
Butttion for power cable: push the button to receive tge cablle automaticlly
AC power socket: output 220V Ac power, suitable for two-pin plug and three-pin plug.
USB interface: output +5V Ac power, supply power for digital products.
Output fuse: AC output power fuse. Model: 250V5A
Handle: foam handle, easy for transportation
Retractable pole: pull out the pole when in use and retract it when in store
Input fuse: AC input power fuse. Model: 250V 5A
Power cable: charging input cable. Extend yje canle to the needed lentth after opening the cover. Retactable manually.
Battery capacity expansion interface: expand the capacity to increase the use time by connecting the battery outside
Slideing wheel: adopts high resilient and hard-wearing PU slide wheel, long lifespan
