colorful cement roof tile press machinery

Specifications

1.ISO 9001 Certificate
2.Speed:6-9pcs/min
3.Method:press & sieve
4.Power:18KW;Pressure:128T
5.Hydraulic & PLC Auto control

Cement roof tile forming machine



1. New type of cylindrical tile molding machine whit high forming speed, large output, and reliable performance. Using PLC (Mitsubishi technology) automatic control, hydraulic pneumatic, the speed of production can up to 6-9 pieces/ min, in a high yield, cost-effective priorities.



2. A new type of cylindrical molding machine, the underside of slid platform is made of semi-circular guide rail, compared with the square guide rail more stable and more wear-resistant. Main oil cylinder and four-cylinder overall orientation, not only to improve the stability of the equipment, but also to extend the life of the mold.



3.Through the filter press type molding, product with beautiful structure, variety kinds, high density, strong strength, accurate size to meet the needs of various types of buildings are concrete products of quality products.





4. A multi-purpose machine, by replacing the mold, can produce various types main tile and matching tiles.



5.The Self-developed plates film can reduce the cost of cleaning up and oiling. The product has applied for a new use of patents.Patent Number. ZL200820085797·X

Technical Parameter



Technical parameter	SMY8-128
Production capacity	6-9 pieces / min
Annual production capacity	900,000pieces(based on 8 hours)
Factory Area	150 square meters
Maintenance area	60 square meters
Total installed capacity	18KW
Manpower quota	4 persons / class
Product specification	424×337mm2



Basic Scheme

No.	Name	Quantity	Unit
1	Forming host	1	set
2	Mixing System	1	set
3	Main mould of the tile	1	set
4	The pallet of the tile	2000	piece
5	Circle Ridge Pallet	50	piece
6	Cornices Pallet	30	piece
7	Circular ridge Manufacturing Machine	1	set
8	Eaves tile manufacturing machine	1	set
9	Drain tile mold	10	piece
10	TY  Three-round ridge	Each1	piece
11	Oblique ridge seal	1	piece
12	Circular ridge seal	1	piece
13	Cornice seal	1	piece
14	Four-way mode	1	piece
15	plastic diaphragm rupport plate	2000	piece
