1000L capacity agricultural tractor pesticide sprayer machine
Tractor mounted and trailed type boom sprayers are developed to meet the different requirements of plant protection treatments. Sprayers extremely versatile and suitable, according to the applications, to operate in open-field cultivations, sprayer and distribute herbicides among the plant rows the availability of several mechanical and hydraulic spraying booms together with different equipments and option allow our sprayers to suit the requirement of the single users in the specific treatments.
With the characteristics of large spraying width, great capacity and high efficiency, the tractor boom sprayer is the ideal tool for small and medium tractors. With 3 cylinder plunger pump or gear pump, it has high working pressure, large flow and is easy to be operated and maintained. This sprayer is generally used to prevent and cure plant diseases and insect pests in gardens or in the fields of soybean, wheat, corn, rice, cotton or patatoes.
Features
1. With function of automatic mixing farm chemical, directly mounted by the tractor.
2. Wide spray width, large capacity, high operating efficiency.
3. Diaphragm pump, high flow, high pressure, corrosion-resistant.
4. Foldable nozzle mast, compact structure.
5. Imported fan spray nozzle, atomization, anti-drift. boom sprayer machine boom sprayer
6. Kits for polyethylene plastic, rigidity, and a variety of drug-resistant corrosion. boom s
7. The whole appearance of using spray coating process, beautiful and durable.
8. Portable auxiliary spray hose is high pressure hose, external connect with gun, artificial spray outside the operating range .
Main technical specifications
Model |
3W-400L |
3W-600L |
3W-800L |
|
Matched power |
20hp |
30hp |
60hp |
|
Tank capacity |
400l |
600L |
800L |
|
Spray width |
8m |
10m |
10/12m |
|
Spray arm |
3 units |
3units |
5uints |
|
Sprayer-head quality |
17 pieces |
25 pieces |
29pieces |
|
Rev of power-output shaft |
540r/min |
|||
Rated spray pressure(pump) |
1.0-2.5 mpa |
|||
|
Flow rate of fluid pump
|
30-100l/min |
|||
Working efficiency |
2-10ha/hr |
|||
Packing Size (mm) |
Main frame
|
2000*1100*1500/ 2pieces |
1500*1150*2600/ 2pieces |
2200*1600*1300/ 2pieces |
Spray arm |
2200*850*530/2 pieces |
4000*850*850/2 pieces |
3200*850*530/ 2pieces |
|
Should you be interested in our products,please feel free to contact me on line or by mail.We would try our best to give the best competitive prcie.Thanks a lot and best wishes.
