Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light

Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light thumbnail-1
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light thumbnail-2
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light thumbnail-3
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light thumbnail-4
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light thumbnail-5
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light thumbnail-6
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light photo-1
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light photo-2
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light photo-3
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light photo-4
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light photo-5
Magic RGB 5050 SMD LED Neon Flexible Strip/tube/rope Light photo-6
Negotiable MOQ: 100 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
San'an Brand SMD5050 LEDs
Input Voltage(V):
12 / 24
Lamp Power(W):
13
Contact Supplier Request Quote Chat Now
Dongguan Wilgex Lighting Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source San'an Brand SMD5050 LEDs
Input Voltage(V) 12 / 24
Lamp Power(W) 13
Lamp Luminous Flux(lm) 1040
Lamp Luminous Efficiency(lm/w) 80
Color Temperature(CCT) Other, Pixel, video, digital color changing
Working Temperature(℃) -20, 60
Working Lifetime(Hour) 50000
Lamp Body Material PVC
IP Rating IP65
Certification CE, EMC, LVD, PSE
Warranty(Year) 2
Place of Origin Guangdong, China
Brand Name WILGEX
Model Number WJ-NF-SMD5050-D-RGB-24V

Wilgex Latest Design Magic RGB5050 SMD LED neon flexible strip/tube/rope Light

 Magic RGB 5050 SMD LED neon flexible strip/tube/rope light



Various lighting effects for our lastest design LED Neon Flex

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light

Product Description

Wilgex LED neon flex features and advantages:

  • 1.  Milky, Crystal and Colored PVC jacket design, and dome/flat/round shapes for different options
  • 2. Smaller in size and extremely flexible
  • 3. Continuous brightness and uniform illumination, no light dot or dark spot
  • 4. Lower power consumption than DIP LED, save 80% energy compared with glass neon
  • 5. Longer lifespan (up to 50,000 hours), firm and durable
  • 6. High brightness, lower heat generating and better heat dissipating, safe to be touched
  • 7. Can be cut into small units, with cutting mark printed on side, and easy to be installed
  • 8. Environmental-friendly, made of non-toxic materials and can be cut and reused
  • 9. Longer warranty 2 years (DIP & Glass neon only 1 year warranty)
  • 10. UV and weather resistant, waterproof IP65 and IP68 available, both indoor and outdoor
  • 11.  Does not interfere with Video/Audio systems nearby
  • 12.  Low voltage or line voltage options, extremely low maintenance costs
  • 13.  Available in all single colors, RGB & Digital RGB colors, magic changing effects
  • 14. Certified by CE(EMC, LVD, EMF), RoHS & PSE authorities.
Specifications of Wilgex SMD LED Neon Flex Rope Light
Wilgex SMD 2835 type LED neon flex--single color
Item No. WJ-NF-SMD2835-15*26mm WJ-NF-SMD2835-10*20mm
LED Type San'an Brand SMD 2835 San'an Brand SMD 2835
LED Spacing 13.9mm 13.9mm
LED qty/M 72pcs 72pcs
Input voltage 230Vac 110Vac 24Vdc 12Vdc 230Vac 110Vac 24Vdc 12Vdc
Cutting length 100cm 50cm 8.33cm 4.17cm 100cm 50cm 8.33cm 4.17cm
Watt/meter 9W/m 9W/m 9W/m 9W/m
Max.loading Length 100m 50m 15~20m 8~10m 100m 50m 15~20m 8~10m
LED color Red, Green, Blue, Yellow, Orange, Purple, Pink
Size 15x26mm 10x20mm

Wilgex SMD 2835 type LED neon flex--single color
Item No. WJ-NF-SMD2835-15*26mm WJ-NF-SMD2835-10*20mm
LED Type San'an Brand SMD 2835 San'an Brand SMD 2835
LED Spacing 10.4mm 10.4mm
LED qty/M 96pcs 96pcs
Input voltage 220Vac 110Vac 24Vdc 12Vdc 220Vac 110Vac 24Vdc 12Vdc
Cutting length 100cm 50cm 12.5cm 6.25cm 100cm 50cm 12.5cm 6.25cm
Watt/meter 9W/m 9W/m 9W/m 9W/m
Max.loading Length 100m 50m 15~20m 8~10m 100m 50m 15~20m 8~10m
LED color White, Warm white
Size 15x26mm 10x20mm

Wilgex SMD5050 type LED Neon Flex -- RGB Color
Item No. WJ-NF-SMD-RGB-15*26mm WJ-NF-SMD-RGB-10*20mm
LED Type San'an Brand SMD5050 San'an Brand SMD5050
LED Spacing 13.9mm 13.9mm
LED qty/M 72pcs 72pcs
Input voltage 220Vac 110Vac 24Vdc 12Vdc 220Vac 110Vac 24Vdc 12Vdc
Cutting length 100cm 50cm 8.33cm 4.17cm 100cm 50cm 8.33cm 4.17cm
Watt/meter 13W/m 13W/m 13W/m 13W/m
LED color Seven colors changing, fading
Max.loading Length 100m 50m 15~20m 8~10m 100m 50m 15~20m 8~10m
Size 15x26mm 10x20mm
Unique design Digital RGB Magic color SMD5050 LED Neon Flex-SPI control
Item No. WJ-NF-SMD-RGB-15*26mm-SPI
LED Type San'an Brand SMD5050
LED Spacing 15.6mm 16.7mm
LED qty/M 64pcs 60pcs
Pixel 4 LEDS/Pixel, 16 Pixels/M  6 LEDS/Pixel, 10 Pixels/M
LED Color Magic color changing (DMX DIY available )
Input voltage 12V DC 24V DC
Cutting length 6.25cm 10cm
Watt/meter 13W/m 13W/m
Max. Loading Length 8~10m 10~15m
LM/M
Brightness		 12.5%: 56.8LM,  25%: 100.8LM, 37.5%: 143.2LM,
50%: 187.80LM, 62.5%: 231.6LM, 75%:276.5LM, 87.5%:320.3LM, 100%: 368.2LM
Size 15x26mm
Comparison of DIP LED with SMD LED Neon Flex

Structure Comparison of Old DIP LED Neon Flex with our New SMD LED Neon Flex

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light



The outlook and lighting effects comparison

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light

How to distinguish the Old DIP type with our New SMD LED Neon Flex?

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light

Heart voice to customers: We are making the Wilgex brand, we cannot give you the lowest price only to give you the highest quality. We would rather explain for the price before sale than to apologize for the quality problems after sale. Thanks for your trust on Wilgex and choosing Wilgex products, we will give you our best quality and best service as feedback :-)





Connection & Control

Power connection drawing of Single Color LED Neon Flex

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light

Control method for RGB LED Neon Flex--- 4 wires 3 loops

Available voltage: DC12V/24V, AC 110V-120V, AC 220V-230V



I: Votage: DC12V/24V connection diagram

 Magic RGB 5050 SMD LED neon flexible strip/tube/rope light

II: Voltage: AC110-120V or AC 220V-230V

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light

Control Method for Digital RGB LED Neon Flex



I:   SPI control connection drawing:

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light

II: Directly DMX 512 programmes control connection drawing:

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light

Application

Wilgex's LED Neon Flex Rope Light is widely used for Path&contour marking,  Elegant interior decoration, Background lighting for big size ad-signs, Landscape outlines, Signal lighting, Swimming pool , Car and motorcycle decorative lighting, Architectural decorative lighting, Archway Lighting, Canopy Lighting,  Bridge edge lighting, Amusement park and theater lighting, Emergency hallway lighting, Emergency Exit path lighting, Auditorium walkway lighting, Stairway accent lighting, Cove lighting.

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light



Certifications:

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light



Packaging & Shipping

Packing:

Wilgex LED Neon Flex is usually packed on wooden reel or high quality plastic reel, you can choose one of them. And each reel packed in a high quality color carton with a User Manual. We also accept to stick your logo on the carton if required :-)

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light

Shipping:

By express: DHL, Fedex, UPS,  TNT or EMS,  from Dongguan, 3~5 days.

By air:  From Shenzhen or Hong Kong, 7~10 days.

By sea: From Shenzhen or Hong Kong, 20~45 days.

Wilgex is trying our best to pack the cargos perfect to prevent damage during delivery, and to make sure the goods shipped to your hands in time and in good condition

Company Information

Dongguan Wilgex Lighting Co., Ltd (originally named Dongguan Jiawen Lighting Co., Ltd), was established in year 2003. We are specialized in developing, designing and manufacturing LED decorating and lighting proodcuts for more than 12 years.

Our products assortment includes LED neon flex, LED wall washer/flood lights, LED fountain/pool lights, and LED undergroud lights as well as garden lights.

All of our products are manufactured to the highest industry standards and utilize some of the best quality components available such as San'an, Edison and CREE LEDs, and MeanWell Power Supplies and are backed by a conservative 2 Year Warranty. All of our products are CE (EMC, LVD, EMF) and RoHS certified and can reach to IP65, IP68 waterproof grade.

We also have PSE certification and sell to Japan market. Our target markets for our LED lights are the middle and high quality required countries such as the USA, Canada, Europe and middle east as well as Japan. Wilgex welcome every clients and partners come to visit our factory in Dongguan city of China.



                                     Wilgex Company and Factory Show

Magic RGB 5050 SMD LED neon flexible strip/tube/rope light
