IP65 Waterproof 360 degree led neon flex tube light
Features & Benefits
• Milky,Crystal and Colored PVC jacket design
• Dome/Flat surface,continous and uniform illumination, no LED dot or dark spot.
• Extremely flexible
• 100% waterproof ( IP65 and IP68 level)
• 100% breakage free
• Low voltage or line voltage options
• Durability,Impact Resistant
• Weather Resistant , UV protection
• Minimal heat output(Safe to the touch)
• Longer life to 50,000 Hours
• Easy to install(Cuttable on location)
• Extremely low maintenance costs
• 80% less energy consumption of glass neon for Wilgex Latest design DMX digital SMD led neon tube light
• Does not interfere with Video/Audio systems nearby
• Available in all single colors,RGB colors & Digital RGB colors
• 2 years warranty
Parameter for Wilgex's 360 degree led neon flex tube light
| Latest design SMD 2835 120PCS type led neon tube light --single color | |||||||||
| Item No. | WJ-NF-SMD2835-15*26mm | WJ-NF-SMD2835-10*20mm | |||||||
| LED Type | SMD 2835 | SMD 2835 | |||||||
| LED Spacing | 0.83cm | 0.83cm | |||||||
| LED qty/M | 120pcs | 120pcs | |||||||
| Input voltage | 220V | 110V | 24V | 12V | 220V | 110V | 24V | 12V | |
| Cutting length | 100cm | 50cm | 8.33cm | 4.17cm | 100cm | 50cm | 8.33cm | 4.17cm | |
| Watt/meter | 9W/m | 9W/m | |||||||
| Max.loading Length | 100m | 50m | 20-25m | 10-15m | 100m | 50m | 20-25m | 10-15m | |
| LED color | Red | Green | Blue | Pink | White | Yellow | Orange | Purple | Warm white |
| Lumen / m | 233 | 388 | 156 | 158 | 450 | 228 | 235 | 158 | 340 |
| Size | 15x26mm | 10x20mm | |||||||
| Latest design SMD 2835 96PCS type LED neon tube light --single color | |||||||||
| Item No. | WJ-NF-SMD2835-15*26mm | WJ-NF-SMD2835-10*20mm | |||||||
| LED Type | SMD 2835 | SMD 2835 | |||||||
| LED Spacing | 1.04cm | 1.04cm | |||||||
| LED qty/M | 96pcs | 96pcs | |||||||
| Input voltage | 220V | 110V | 24V | 12V | 220V | 110V | 24V | 12V | |
| Cutting length | 100cm | 50cm | 12.5cm | 6.25cm | 100cm | 50cm | 12.5cm | 6.25cm | |
| Watt/meter | 7W/m | 7W/m | |||||||
| Max.loading Length | 100m | 50m | 20-25m | 10-15m | 100m | 50m | 20-25m | 10-15m | |
| LED color | Red | Green | Blue | Pink | White | Yellow | Orange | Purple | Warm white |
| Lumen / m | 233 | 388 | 156 | 158 | 450 | 228 | 235 | 158 | 340 |
| Size | 15x26mm | 10x20mm | |||||||
Control method for RGB LED Neon Flex tube light --4 wires 3 loops
Available voltage:DC12V/24V
Votage:DC12V/24V connection diagram
Control Method for Digital RGB LED Neon Flex tube light
I: SPI control connection drawing:
II: Directly DMX 512 programmes control connection drawing:
Power connection drawing of Single Color led neon tube light
Main Machine for led neon flex tube light
Application for LED Neon tube light
LED Neon Flex tube light is widely used in city lighting engineering, architectural outline sketch, business travel façade decoration, billboards, taxi signing ballroom, stage, background production and a large number of places such as night scene decoration.
Certifications:
Package:
Our Promise: 1. Provide solutions and high quality products
2. Streamline the buying and paying processes
3. Deliver the goods to our customers all over the world with speed and precision
4. Protection of your sale area, ideas of design and all your private information
Our Service: 1. Provide professional person to communicate with you before the order.
2. Provide strict quality check for each part, each process before export.
3. Provide optimum system solution based on each client’s specific requirement.
4. Send extra accessories to help fix the lamp for free international express.
If accessories can’t solve the problem, we will send you the replacement lamp directly.
Dongguan Wilgex Lighting Co., Ltd (originally named Dongguan Jiawen Lighting Co., Ltd), was established in year 2003. We are specialized in developing, designing and manufacturing LED decorating and lighting proodcuts for more than 12 years.
Our products assortment includes LED neon tube light, LED wall washer/flood lights, LED fountain/pool lights, and LED undergroud lights as well as garden lights.
All of our products are manufactured to the highest industry standards and utilize some of the best quality components available such as San'an, Edison and CREE LEDs, and MeanWell Power Supplies and are backed by a conservative 2 Year Warranty. All of our products are CE (EMC, LVD, EMF) and RoHS certified and can reach to IP65, IP68 waterproof grade.
Fast link for other product from our 360 degree led neon flex tube light
LED Wall Washer LED Neon tube light LED Unterwater Light LED Garden Lamp LED Stage Light
