Help Center3IN1 DC Adapter
US$ 8 - 11
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
YH POWER
Model Number:
YH-8070
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
YH POWER
Model Number
YH-8070
Usage
Laptop
Specifications
1.home and car laptop DC adapter2.CE,RoHS compliance availabel
3.12 months warranty
4.USB can charger laptop,MP3/4,etc
| YH-8070 3 IN 1 DC ADAPTER Specification | ||||
| Products specification | ||||
| No. | Item | SPC | ||
| 1 | Model | AC | DC | |
| 2 | Rated Input Voltage | 110V/230V 50Hz/60Hz | 12V | |
| 3 | Input Voltage Range | 100V-240V 45Hz-65Hz | 11V-14V | |
| 4 | Output Power | 100W | 100W | |
| 5 | Input Rated Current | 1.14A | 10A | |
| 6 | Input Power | 114W | 120W | |
| 7 | Output Current | 12V/15/16/18/19V | 5.26A MAX | |
| 8 | 20V/24V | 4.17A MAX | ||
| 9 | Output Voltage | 12/15/16/18/19/20/24V | 0~+0.5V NO LAOD | |
| 10 | 12/15/16/18/19/20/24V | ±0.3V Rating LOAD | ||
| 11 | USB Output:5V DC | 1.0A MAX | ||
| 12 | Efficiency | >88%(TYP) | ||
| 13 | Short circuit Protection | YES | ||
| 14 | Overload protection | YES | ||
| 15 | Ripple Noise | 500mV | ||
| 16 | Line Regulation | 1% | ||
| 17 | Load Regualtion | 1% | ||
| Environment Requirement | ||||
| 1 | Operating Temperature | 0C to 40C | ||
| 2 | Humodity | 20% to 80% | ||
| 3 | Storage Temperature | -10C to 70C | ||
| 4 | Storage Humidity | 10% to 90% | ||
| Advantage | ||||
| 1 | 1 | USB charger function | ||
| 2 | 2 | Stablized output,low ripple&low interference | ||
| 3 | 3 | Adjustable output voltage | ||
| 4 | 4 | High efficiency&low energy consumption | ||
| Universal distribution DC plug spec | ||||
| Series Num | Outside path | Inside path | length | |
| 1 | 6 | 3.2/1.4 | 13 | |
| 2 | 6.3 | 3 | 13 | |
| 3 | 5.5 | 3 | 12 | |
| 4 | 5.5 | 2.1 | 12 | |
| 5 | 5.5 | 1.7 | 12 | |
| 6 | 4.8 | 1.7 | 11 | |
| 7 | 4 | 1.7 | 11 | |
| 8 | 3.5 | 1.35 | 11 | |
| DC bent tips connector | |||||||
| A | 6.0*1.0 | Fujitsu, Sony, Panasonic etc | |||||
| B | 6.3*3.0mm | Toshiba 15V/3A,15V/4A etc., NEC etc | |||||
| C | 5..5*3.0mm | Samsung 19V/3.16A,19V/3.75A;19V/4.22A, | |||||
| D | 5.5*2.1mm | Acer, Lieton ,NEC, Compaq etc | |||||
| E | 5.5*1.7mm | Acer, Toshiba etc | |||||
| F | 4.8*1.7 | Compaq/HP 18.5V, Delta,Asus, NEC 19V | |||||
| G | 4.0*1.7mm | Samsung Q20 | |||||
| H | 3.5*1.35mm | For Sharp | |||||
