Specifications
1.60v 15A 60v solar regulator2.rating voltage60v with LED display
3.packed by neutral white box
4.1 year warrant
Mode introduction and setting form: 60v 15A solar dc voltage regulator
60v solar regulator Controller has three modes and the setting form is just as follows:
LED dispaly |
Mode |
LED dispaly |
Mode |
1 |
One hour's light time |
0 |
10 hours' light time |
2 |
2 hours' light time |
1 |
11 hours' light time |
3 |
3 hours' light time |
2 |
12 hours' light time |
4 |
4 hours' light time |
3 |
13 hours' light time |
5 |
5 hours' light time |
4 |
14 hours' light time |
6 |
6 hours' light time |
5 |
15 hours' light time |
7 |
7 hours' light time |
H |
Houser system |
8 |
8 hours' light time |
F |
pure light control sytem |
9 |
9 hours' light time |
Technology qualification
System voltage |
60v |
System current |
15A |
No-load loss |
Less than 10 mA |
Solar energy input voltage |
Less than 110v |
Over voltage protection |
82.5v |
Over voltage recovery |
75v |
Balance charge voltage |
72v(25 °C) time maintenance 1H |
Increase charge voltage |
72v(25°C) time maintenance 1H |
Float charge voltage |
69v (25 °C) |
Charging return voltage |
66.5v (25 °C) |
Discharge protection voltage |
66.6v |
Discharge protection voltage |
64v |
Temperature compensation |
-4.0mv/ °C/2V |
Daytime identifying voltage |
35v |
Night identifying voiltage |
15v |
Over-load,short circuit pretection |
1.5 times rating current 30S 1.5 times rating current 10S overload current protection ≥3 times rating current short circuit protection |
Work temperature |
-25 °C to + 60 °C |
Protection degaree |
IP 30 |
Outline size |
141.5mm*84mm*23.6mm |
weight |
0.35kg |
Function
1.60v rating voltage by system
2.LED digital display and one-key operation, easy to use.
3.The improved 3-section computing method can weekly give the battery a balanced charging. It can stop the battery the battery from being unbalancing and vulcanizing and let the battery been used for more time.
4.The controller is quipped with the serial PWM charging main circuit with additional 3% - 6% efficiency than the non-PWM circuit which can work more time and increase the suing period of the system.
5.Controller has three load work ways and can be easily used in the varies streetlights and monitors.
6.Visualized LED display which can let he users get to know the conditions of the solar power and storage battery.
7.Overcharge. Over discharge and overload protection. Reverse connect preventing protection.
8.Lightning prevention
Pictures
