Hot Sale Aseptic Tube-in-tube Sterilizer
US$ 10,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, New
Place of Origin:
Jiangsu, China
Brand Name:
KAAE, KAAE
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2014 Hot Sale Plate Sterilization for Liquid ProductUS$ 1,000 - 50,000MOQ: 1 Set -
Vibration Screen Used for Fruit Industry Made in ChinaUS$ 1,000 - 10,000MOQ: 1 Set
-
Hot Sale Stainless Steel Rotating Filter ScreenUS$ 1,000 - 10,000MOQ: 1 Set
-
Hot Sale 2014 Industrial Tangerine Fruit Oil Mill Machine Manufactured in Wuxi KaaeUS$ 10,000 - 20,000MOQ: 1 Set
-
Hot Sale 2014 Industrial Orange Fruit Oil Mill Machine Manufactured in Wuxi KaaeUS$ 10,000 - 20,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
KAAE, KAAE
Type
Other, Sterilization
Voltage
220/380V, 220/380V
Power(W)
As per the capacity
Weight
As per the capacity
Dimension(L*W*H)
As per the capacity
Certification
CE, ISO, CE, ISO
Warranty
1 year, 1 year
Wuxi Kean Automation Equipments Co.,Ltd.
Leading Company of the Fruits and Vegetables Processing Industry
Tubular UHT sterilizer advantage
1 High heat efficiency, 90% of heat reused.
2 Automation control
3 Sterilize thoroughly and fully
4 with self CIP and SIP system
Usage of sterilizer
1 Mainly used for aseptic filling packing types products, such as tetra paper brick, tetra paper pillow, aseptic soft plastic bag, aseptic PET bottles,especially used for liquid milk and juice.
2 It can be used to do continuous sterilizing and be connected to homogenizer and water removing equipment.
Technical Data
| Model | KATG-UHT-1.5 | KATG-UHT-3 | KATG-UHT-5 |
| Capacity(L/H) | 1500 | 3000 | 5000 |
| Inlet temperature | 25-40°C | 25-40°C | 25-40°C |
| Holding temperature time(s) | 120-180 | 120-180 | 120-180 |
| Sterilizing temperature | 95-121°C | 95-121°C | 95-121°C |
| Outlet temperature | 25-35°C | 25-35°C | 25-35°C |
| Tower water inlet temperature(°C) | -30 | -30 | -30 |
| Steam pressure | 0.5Mpa | 0.5Mpa | 0.5Mpa |
| Steam consumption | -150Kg/h | -210Kg/h | -280Kg/h |
| Compressed air pressure | 0.6Mpa | 0.6Mpa | 0.6Mpa |
| Compressed air consumption | 50L/H | 50L/H | 60L/H |
| Overall dimensions(L*W*H) | 7000*2000*2000 | 7000*2000*2000 | 7000*2000*2000 |
| Weight | 1700Kg | 2000Kg | 2200Kg |
