Specifications
1). fast installation and easy to operate2). Low repair and maintenance costs
3).high efficiency
downspout roll forming machine
1. Profile |
customized
|
2. Process flow |
Decoiling--feeding---levelling--forming---measuring---cutting---production
|
3. Decoiler |
Manual decoiler il inner diameter: 450-550mm il max width: 1250mm 3.max carrying capacity: 5000kg |
4.Forming device |
1. Shaft material & rollers material & shaft diameter 45# steel adjustable treatment; 45# steel, polished, plate of chrome 0.05mm; 60mm 2. power: 101kw 3. Transport; Motor; chain drive 4. Forming speed; 10-15m/min
|
5. Cutting device |
1). Material: blade, puncher and mold material: Cr12 steel with quenched treated 60-62 2).Cutting system: advanced hydraulic drive, automatic cutting after forming, no distorting or wasting, high level safety factor. |
6.Controlling device |
It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products.
|
7. Hydraulic |
1. Advanced hydraulic system from Taiwan 2. Power: 3kw |
8. Spare parts |
1. easy damaged parts: conk 2 pcs, fuse-link 4 pcs 2. rubber mat 1 pcs; 3. bolt spanner 1 pcs |
Payment Terms: 30%T/T after signed the contract,balanced before delivery
Warranty
1). One year, and we will provide the technical support for the whole life.
2).Training: the buyer should charge of visa, return ticket, food and accommodation overseas and
USD50/person/day for salary.
3). Need one technicians
4).Training time: one week (contains the time of installation and adjustment)
