Stainless steel sheet hole stamping machine , metal plate press machine
Material : Stainless steel plate
Material thickness : 0.8-1.5 mm
Material width : Max 1250 mm
Holes density : 10 % - 25 %
Work Flow:
|
1.
Decoiler
|
Usage: It is used to support the steel coil and uncoil it in a turntable way. Passive uncoil pulled by roll forming system. Decoiler type: Manual Loading capacity: 5T Uncoiling width: 1250mm Inner diameter: 450-550mm
|
|
2.
Flattener |
Usage: The coil from Decoiler is a little bit curves, so the leveling system is to help make the coil straight, neat and clear. We will take 11 rollers, upper 5 rollers and down 6 rollers to level the coil. leveling Rollers: 11 Rollers Diameter: 80 mm Leveling thickness: 0.8-1.5 mm Max leveling speed: 12 m/minute Drive type: Gear Motor power: 3 kw |
|
3.
Punching Machine
|
The specification of the the punching system: 1. Press tonnage : 200 T 2. Layout Form: Standing type 3. Size : 2.5*1.6*1.8 m (H*W*L) 4. Model No : J 21-200 T (GANTRY TYPE) 5. Punching machine weight : 10 T(The whole line weight 14 tons) 6. Power type: Electric power 7. Voltage: 380 V 50 Hz 3 Phrase 8. Feeding power: 1.5 kw 9. Main motor power: 18.5 kw 10. Slider trip: 30 mm 11. Slide Strokes: 55-60 times/minute 12. Punching speed: 1.5-2.5 meters /minute 13. Feeding type: Automatic servo feeding (Automatic stop when punching) 14. Punching mould: 2 sets (Double line mould, each time double line of holes) |
|
4.
Cutting Feeder |
Usage: The machine automatically stops when cutting. After the cutting, the machine will automatically start. Feeding Rollers: 7 rollers Diameter: 80 mm Feeding thickness: 0.8-1.5 mm Max feeding speed: 12 m/minute Drive type: Gear Motor power: 4 kw
|
|
5.
Hydraulic Cutting |
Feature : Ensure stability, precision and cutting speed Function : Automatic cutting controlled by PLC. It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products. The main machine automatically stops and then cutting. After the cutting, the main machine will automatically start. Material of blades: Cr 12 quenched HRC 58-60. Power supply : Hydraulic power Components: The system includes a set of hydraulic tank, a set of hydraulic oil pump, four hydraulic pipes and two sets of electromagnetism valves. |
|
6.
Receiving Table |
Table for reception of the cut profiles with roller transporter allowing to unload the cut profile freely. Frame: Welded by square tube Size: 2.0 m*1.0 m*0.9 m (L*W*H) Supporter roller: ASTM 1045 with chrome Diameter of rollers: 55 mm Quantity: 3 Sets
|
Warranty |
1. One year warranty, whole life technical support. 2. Installation & adjustment : We can take a video for the customer and the customer can also come to our factory, we can train customer how to install and adjust the machine. 3. Oversea service: the buyer should charge of visa, return ticket, food and accommodation overseas and USD 50/person/day salary. |
