Specifications
The wide format UV flatbed printer has high speed up to 26sqm/hr.Printing format: 2.54*1.22m
Features
1. The PP2512UV turbo flatbed printer uses piezoelectronic Konica Minolta 1024 print heads
2. The wide format UV flatbed printer has high speed up to 27sqm/hr.
3. Printing format: 2.54*1.22m
4. The printing machine uses white ink for base color, covering color, spot color, and also offers varnish solution.
Automatic Anti-crash Sensor
The safety anti-crash sensor design can detect the state of the media beforehand and protect the print heads from a crush hazard. While the anti-crash sensor detects that the edge of media is tilted, the turbo flatbed printer will initiate an emergency stop to prevent print head from damage.
Roll-fed Media Support Optional Roll-to-Roll Printing
Optional Roll-to-Roll upgrade kit supports flexible media up to 250cm wide, with a roll diameter 30cm, and up to 100kg in weight.
Automatic Medium Calibration
The automatic medium calibration unit automatically detects and gauges the distance between the print heads and loaded media, and then automatically adjusts to the optimized print height based on the thickness of the loaded media.
White Ink Recirculation
White ink recirculation results in an effective elimination of ink starvation, and protects print heads from clogging hazard.
High Resolution and Quality Image Output
Greyscale print heads produce quality images with saturated colors and smooth gradations.
White Ink Applications
The PP2512UV turbo flatbed printer offers eight major applications of utilizing white ink as a base color, covering color, fill color, spot color, or under the spot color, over the spot color, etc. Applying white ink is the most common application for dark or transparent substrates to highlight and present the most vivid of graphic.
Varnish Solution
Optional varnish not only enhances the visual quality but also creates the tactile attribute of graphics. Users are able to apply varnish directly on graphics via print heads as either an all-over coating or as a spot-highlighting, giving your printings more vivid and brighter finish.
Three-Layer Printing Innovation
The PP2512UV wide format UV flatbed printer has the function of three-layer (such as: CMYK+W+CMYK) printing intellectualized and controlled by software, which can carry out synchronously double-sided printing on any transparent substrate.
Technical Specifications
Print head |
4-8 Konica Minolta 1023 printheads |
Print modes |
Standard output mode: 26 sqm/hr Production mode: 18sqm/hr Ultra-high quality output mode: 13.5sqm/hr |
Print resolution |
Up to 1440x1440dpi |
Technology |
Piezoelectric inkjet, UV-curable inkjet, greyscale printing. |
Color |
Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, White (optional), Varnish (optional) |
Ink types |
UV-curable, pigment-based ink |
Ink cylinder size |
4 liter (CMYK, LC, LM, W, V) |
RIP software |
Photoprint Flora Edition, Onyx (Optional) |
Color management |
ICC based color management, adjustable curve and density |
File formats |
TIFF, JPEG, Postscript, EPS, PDF, etc. |
Media handling |
Flatbed, sheet feed, and roll feed with optional Roll-to-Roll upgrade kit. Vacuum platform supports various rigid materials. Automatic media registration system is used for easy loading and accurate printing. With an optional, unique blowing function, it makes medium unloading very easy. |
Rigid media |
Standard vacuum table support rigid materials up to 254x122cm, 50kg/sqm |
Roll-fed media |
Optional Roll-to-Roll upgrade kit supports flexible media up to 250cm wide, with a roll diameter 30cm, up to 100kg in weight |
Thickness |
Up to 100mm |
Data transmission | |
Data interface |
High speed USB transmission |
UV energy source |
Dual shuttered UV lamps, independent user-selectable control of shutter aperture and two lamp power levels |
Dimensions (l x w x h) |
480x260x144cm, Shipping: 500x246x150cm |
Printer weight |
2000kg |
Operating conditions | |
Temperature |
20 to 30°C |
Relative humidity |
20%-80%, non-condensing (minimum 40% recommended for synthetic media to avoid static electricity; maximum 60% recommended for paper-based media to avoid buckling |
Power supply | |
Maximum power |
8500 watts |
Requirements |
Input voltage: 200to 240VAC, signal-phase, 50/60Hz, 32A max. |
