UV flatbed printer on Spectra Polaris printheads 5m printing wide

Specifications

16 Spectra Polaris print heads
4/6 colors
Highest printing resolution of 1200dpi

Technical Specification

Model: HJ 5000 UV

Printing heads: Spectra Polaris

Quantity of printheads: 16 heads

Colors: 4/ 6 colors

Resolution options: 360*360/ 720*720/1440*1400 dpi



The HJII5000UV is now available in a 4 Color or 6 color configuration, featuring 16 Spectra Polaris print heads. The UV lamps instantly dries the UV-curable Premium inks, these specially formulated inks yield a wider color gamut and exhibit excellent flexibility and superior adhesion on a variety of materials fabric, canvas, vinyl, plastic film, paper and polyester including 100% PE eco-friendly opening many new markets. Capable of printing fast high quality images at speeds of 252 sqm/hr in 2-pass Billboard mode at 1200 dpi, which is perfect for Outdoor application. It is the most productive digital solution for outdoor applications in speed and quality for billboards and building wraps.



1. High Resolution and High Speed Printing

HJII5000UV can be equipped with up to 16 Spectra Polaris print heads, with option of 4 and 6 colors. Capable of printing fast high quality images at speeds of 252 sqm/hr in 2-pass Billboard mode. The highest resolution can be up to 1200 dpi. This is a perfect for Outdoor application.



2. Environmentally friendly UV-curable inks

Flora HJII 5000UV gives the prefect print with brighter images and solid colors using dedicated environmentally friendly UV-curable Premium inks, these specially formulated inks yield a wider color gamut and exhibit excellent flexibility and superior adhesion on a variety of materials including 100% PE eco-friendly. Instant UV curing that increase usable output, reduce waste and increase profits.



3. Wide variety of substrates UV ink can print on variety of substrates. UV ink Prefect for the following applications: billboards, building wraps, displays, exhibition, event graphics, exterior signage, indoor posters; interior decoration, murals, point of sale/display, POP/POS, double-sided backlit, double-sided banners.



 4. Maximum material width up to 5.0 wide

Capable of printing 5m width materials in one time, save the time

of substrate’s connecting. Create more of profit for users.



5. Multiple rolls of Substrates print synchronously

Capable of printing multiple rolls of substrates synchronously, which enhance productivity and reduce the labor cost.



6. Double sides printing

HJII5000UV can carry out double sides printing. The printing position can be adjusted by software, which ensure the picture s’ contraposition precision of the front side and the back side.



7. UV Lamp safe prection device

This device can be in effect to avoid the operator to osculate UV light directly.



8. Infrared Safeguard

Infrared Safeguard can auto detect the impediment of the Take up& Feeding system. Ensure the secure production.



9. Industrial Take up & Feeding System

Capable of handling 360kg rolls for jumbo roll printing. Grade-style winders that make it easy to load and unload for quick job turn-over.



10. Innovative Substrates feeding System

Multi point-floating tension system, which ensure the substrate move accurately and smooth.



11. Auto Tension Servo control System

Auto tension Servo control System ensure printer can print on different thickness substrate.



12. Metal raster strip & optical fiber system

Metal raster strip wears well, not easy to fray with high precision, ensure the high resolution output; Optical fiber system mate sure the high speed and high capacity data transfer.



 13. Compatible Windows XP & windows 7.

Flora HJII5000UV systems Compatible Windows XP & windows 7



 14 Servo motor for print head carriage and feeding system

Servo motor for print head carriage and feeding system ensure the substrate feeding accurately and high quality printing output.
