2 inch video microwave telecoms Digital Fiber-Optic Transmission Equipment
Description:
Fiber-optic video transceivers can simultaneously transmit 1 channel of 8-bit digitally encoded broadcast quality video/return or bidirectional data/unidirectional or bidirectional audio/Ethernet/Telephone/Dry contact over one multimode or single-mode optical fiber.
These multiplexers are typically used in applications where the cameras have P/T/Z capabilities.
Devices are available for either standalone or rack-mount installation, which is suitable for different working environment.
Features:
1.Support any high-resolution video signal
2.Power supply and other parameter state indication, which can monitor the operation condition of system
3.Support no-damage regenerative trunk of video
4.Constant input optical power, and large dynamic range ,no Electrical or Optical Adjustments Required .
5.Special ASIC design .
6.Industry-grade of operating temperature from -10°C to 65°C , which is
7.applied to the different working environment
Specifications
1.manufacturer
2.best material,quick delivery
3.dimension:105x104x28mm
4.3-year warranty
5.digital optic transmission
video characteristics |
Video interface number |
4- channel video |
Signal system |
PAL/NTSC/SECAM |
|
Nominal input & output level |
1Vp-p |
|
Nominal input & output impedance |
75Ω |
|
Bandwidth of each channel |
6.5MHz |
|
Sampling frequency |
16.6MHz |
|
Quantification grade |
8bit |
|
Differential gain |
1% typical value |
|
Differential phase |
1° typical value |
|
Weighted signal-to-noise ratio |
63dB typical value |
|
Ethernet Data |
Channel number |
1 |
Nominal; |
ANSI X3T12TP-PMD |
|
Protocol |
IEEE 802.1q VLAN |
|
Working mode |
10/100M full /half duplex self-adaptive |
|
Throughput rate |
100% |
|
Packet loss rate |
0 |
|
Connector |
Audio Connector |
BNC |
Fiber Connector |
FC/PC(or ST/PC) |
|
Power supply Connector |
2 port Power supply |
|
Telephone characteristics |
Telephone interface number |
1-4 channel telephone (optional) |
Interface Port |
RJ-11 |
|
Impedance |
600Ω |
|
Audio range |
300-3400KHZ |
|
Loss |
300-600HZ>12Db 600-3400HZ>15dB |
|
Voice Bandwidth |
80KHZ |
|
Working mode |
point to point, SPC / extension |
|
Dimension |
9.8cm*13.3cm*2.7cm |
|
Packing:
1/carton box,or according to customer request
Shipping:
in 7 days after receipt of deposit
