Flexible Hose, Concrete Pump Tube,concrete Pump Hose

Flexible Hose, Concrete Pump Tube,concrete Pump Hose thumbnail-1
Flexible Hose, Concrete Pump Tube,concrete Pump Hose photo-1
US$ 0.18 - 6.23 MOQ: 50 Meters
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Kiynn
Model Number:
concrete pump hose
Contact Supplier Request Quote Chat Now
Laizhou Qi Yuan Plastic Products Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Kiynn
Model Number concrete pump hose

Specifications

1.Abrasion<0.1
2.The max length is 20M
3.widely used in shipbuilding
4.factory direct sale
5.can be customized

flexible hose, concrete pump tube,concrete pump hose



Applications:

Useful of sand blast machines. it can be used for removing rust

Inner layer:

1.material:NR/SBR/BR/NBR/EPDM



2. feature:good at wear-resistance, anti wear, strong fatigue resistance, long



lifespan,



Framework:

 employing fine fabric (canvas) or chemical fabric cloth

.

Outer layer:

1.material:NR/SBR/BR/NBR/EPDM



2. feature:The tube body is light,  Anti-bending of aging, ozone resistance,



toughness and wear resistance  Visual effect is good



Suitable temperature:-40 ~ +90 °C

Length: 20/40m

Technology parameters



Inner diameter

I.D.

Working pressure

W.P.

Blasting pressure

B.P.

Weight

Kg/M

mm

 inch

Psi

Mpa

Psi

Mpa

8

5/16

42~170

0.3~1.2

126~510

0.9~3.6

0.23

9.5(10)

3/8

42~170

0.3~1.2

126~510

0.9~3.6

0.26

13(12.7)

1/2

42~114

0.3~0.8

126~340

0.9~2.4

0.36

16

5/8

42~114

0.3~0.8

126~340

0.9~2.4

0.53

19

3/4

42~114

0.3~0.8

126~340

0.9~2.4

0.64

25

1

42~114

0.3~0.8

126~340

0.9~2.4

0.85

32

11/4

42~114

0.3~0.8

126~340

0.9~2.4

1.20

38

11/2

42~114

0.3~0.8

126~340

0.9~2.4

1.39

45

13/4

42~114

0.3~0.8

126~340

0.9~2.4

1.62

51

2

42~114

0.3~0.8

126~340

0.9~2.4

1.80

58

23/8

28~114

0.2~0.8

85~340

0.6~2.4

1.85

64

21/2

28~114

0.2~0.8

85~340

0.6~2.4

2.02

76

3

28~114

0.2~0.8

85~340

0.6~2.4

2.41

89

31/2

28~114

0.2~0.8

85~340

0.6~2.4

2.78

102

4

28~70

0.2-0.5

85~200

0.6~1.5

3.16

127

5

28~70

0.2-0.5

85~200

0.6~1.5

3.87

152

6

28~70

0.2-0.5

85~200

0.6~1.5

5.13

178

7

28~70

0.2-0.5

85~200

0.6~1.5

6.15

203

8

28~42

0.2~0.3

85~126

0.6~0.9

6.97

254

10

28~42

0.2~0.3

85~126

0.6~0.9

9.78

305

12

28~42

0.2~0.3

85~126

0.6~0.9

13.03

457

18

28~42

0.2~0.3

85~126

0.6~0.9

24.28





Packing: Plastic inner side and woven outer side,Color packing or customized

Note:1)The weights above are all theoretical values, and the actual

weight needs to be re-determined as the customer’s requirement.

           2)Requirements for special working pressure, length, or colors

may be satisfied according to orders.

           3)We can product the size(inner diameter)of you need,it

include:3/4,1,1-1/4,1-1/2,1-3/4,2,2-3/8,2-1/2,3,3-1/2,4,5,6,7,8,10,12,18 ect





If you have any questions ,pls contact with me at any time!
