CE ISO approved fish feed pellet machine
- 204 Set / Sets per Month
- Qingdao port china
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | Dongfang |
Model Number: | DFKL508-01 | Type: | Feed Pellet Machine | Voltage: | 380-440V |
Power(W): | 132kw | Dimension(L*W*H): | 3200*1650*2200 | Weight: | 4650 kg |
Certification: | CE | Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CE ISO approved fish feed pellet machine
1. Introduction Of fish feed pellet machine
Ring die pellet mill is an ideal pelletizing machine for high quality feed pellets.
Before pelletizing, grains such as corn, wheat, rice and soybean etc.need to be crushed into powder fristly.
Also they should be mixed throughly with a mixer with other additives may be added to ensure a balanced feed formulation.
Ring die feed pellet mill is widely adopted by livestock farm, poultry farm,
feed processing industry and aquaculture.
2. Different Requirements for fish feed pellet machine
Different animals have special requirements of pellets,
we have several types of ring die pellet mills which can respectively produce livestock feed pellets,
poultry feed pellets, aquatic feed pellets, etc.
a. For pig, the pellet diameter is usually ø3.5-6.5mm.
b. For cattle, the pellet diameter is usually ø4.5-8mm.
c. For chicken, pellet diameter is usually ø3.2mm.
d. For fish, pellet diameter is usuallyø2.0, ø2.5, ø3.0mm.
e. For shrimps, pellet diameter is usually ø1.0-ø3.5mm.
3. Features Of fish feed pellet machine:
a. Adopt aerodynamic technology, reducing the temperature in pelletizing chamber to
around 90°C, therefore the machine can work well continuously.
b. Using spheroidal graphite cast iron, the machine body is more durable.
c. Treated by hardness quenching and milling machine,the gears maintain high
concentricity with the shaft, Thus ensuring a good performance and large capacity than belt driven models.
d. With lubrication system, you can add grease to main shaft without having to turn off the machine .
e. The ring die mould are cast by heat processing technology, thus having a durable life and producing qualified pellets.
f.Equipped with an advanced compensation serpentine-spring coupling which connects the pelletizing chambert with the motor to increase safety and stability.
g. Permanent magnet device can remove impurities in the pelletizing process.
h. Multi-layer conditioners can be installed to improve quality of aquatic feed pellets.
4. Unique Characters of fish feed pellet machine:
a. Unlike materials that are used to make wood pellets, grains for making feed pellets can get into the pellet machine just through gravity,
thus imperative feeding device is not necessary.
b. During the pelletizing process, steam should be added through the steam pipe . T
he steam can accelerate the ripening of materials and the finished pellets are easy to digest for animals.
c. Multi-layers can be mounted to produce certain high-grade feedstuff pellets.
5. Parameter for fish feed pellet machine
Model | Output | Main Power | feeder power | Conditioner power | Ring die Diameter | Dimension | pellets size |
ton/h | kw | kw | kw | mm | |||
DFKL320 | 2-4 | 37 | 0.55 | 2.2 | φ320mm | 2100x800x1300 | 1.5-18mm |
DFKL350 | 3-5 | 55 | 0.55 | 2.2 | φ350mm | 2200x900x1500 | |
DFKL420 | 6-10 | 90 | 1.5 | 5.5 | φ420mm | 3200x1100x1700 | |
DFKL508 | 8-15 | 132 | 1.5 | 5.5 | φ508mm | 3200x1300x1900 | |
DFKL600 | 5-22 | 160 | 1.5 | 5.5 | φ600mm | 3800x1600x2800 |
6.Process of fish feed pellet machine
(1)Crushing Process:
When the thickness of the raw material is >5 mm, the raw materials must first be used for size reduction before the feedstock is sent to the hammer mill (crusher) to reach a diameter of less than 3 mm.
(2)Mixing Process:
Two open doors structure, discharge rapidly, no leakage, no residue. Multiform liquid adding system and can be matched with compressed air jetting system Suitable for mixing premix, poultry feed, aquatic feed, additives and chemical and medicine industries, etc
(3)Pelletizing Process:
Acting as the heart part of the whole processing line, ring die pellet machine adopts mechanical feed, high speed rotating centrifugal distribution into the granulating chamber, through the scraper to distribution materials, feeding uneven. but the finished products have strong internal structure and smooth surface.
(4)Cooling Process:
After the pelletizing process, the temperature of the feed pellet is about 60-80 degrees Celsius, with a moisture content of about 15%.A Cooler must then be used to reduce the moisture content of the wood pellets to about 3-4%, thereby making the wood pellets easier to store.
(5)Classifying screen:
It is applicable for screening and classifying of mash or pellet feed. It is also can be used for cleaning of raw materials andclassifyingof semi finished products after second grinding by large and medium feed mills.
(6)Packing Process:
After cooling and screening, the feed pellet must be protected from moisture and other environmental conditions. For this there is the packing process, which is effectively handled by our Semi-Auto Packing Machine.
Generally, most clients require a small scale with the auto-sealing packing machine and a scale for higher weight ranges for the semi-auto packing machine. For the first, the weight range is 15-50 kgs per bag, and for the second, it is 800 or 1000 kgs, modified per clients’ needs.
7.Live pictures Of fish feed pellet machine:
8. Dongfang Group----Our factory pictures:
Please kindly contact with me if you need pellet machines. I will be very glad to serve you here!-----Helen
