Specifications
Driven by Ac servo motorTable automatic feed on X/Y/Z
Automatic rapid feed X/Y/Z
Specifications |
Unit |
XL6436 |
XL6436C |
XL6436CL |
Table size |
mm |
1325*360 |
1325*360 |
1600*360 |
Table travel (X/Y/Z) |
mm |
750/360/460 |
1100/360/450 |
1300/360/450 |
Table feed(X/Y/Z) |
mm/min |
30-750/20-500/15-375 |
30-750/20-500/15-375 |
30-750/20-500/15-375 |
Spindle taper |
7:24, ISO50(H) 7:24, ISO40(V) |
7:24, ISO50(H) 7:24, ISO41(V) |
7:24, ISO50(H) 7:24, ISO40(V) |
|
Arm travel |
mm |
550 |
550 |
550 |
Distance between spindle nose and table |
mm |
200-660 |
200-660 |
200-660 |
Distance between horizontal nose and arm |
mm |
20-480 |
20-470 |
20-470 |
Distance between spindle and arm |
mm |
200 |
200 |
200 |
Spindle speed range |
rpm |
12 steps, 60-1750 |
12 steps, 60-1750 |
12 steps, 60-1750 |
T-slots(N/W/D) |
|
3/18/70 |
3/18/70 |
3/18/70 |
Arm travel |
mm |
550 |
550 |
550 |
Main motor power |
kw |
5.5(H), 4(V) |
5.5(H), 4(V) |
5.5(H), 4(V) |
X/Y/Z feed AC servo motor torque |
Nm |
10 |
10 |
10 |
Overall size |
mm |
1800*2100*2022 |
1800*2100*2022 |
1800*2100*2022 |
Net weight |
kg |
2685 |
2750 |
2800 |
Product Description:
1. Pass the ISO9001 and CE Certificate
2. High rigidity, capable of heavy load cutting
3. Swivel head, rotary table
The machine is suitable for machinery, light industry, instrument, motor, electrical appliance and moulds, and widely used in machining of plane and arbitrary angle plane, and slotting, drilling, reaming, boring etc.
Standard accessories:
1. Plain vice
2. ISO50 Milling chuck
3. ISO50 Cutter arbor
4. Drawbar
5. Inner hexagon spanner
6. Double head wrench
7. Single head spanner
