XL6036 Servo Motor Horizontal Knee-type Milling Machine

Name: XL6036 Servo Motor Horizontal Knee-type Milling Machine
Brand: XILI
SKU: 106418359
Availability: InStock

US$ 1 - 2 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

XILI

Tengzhou Xili Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name XILI

Model Number XL6036

Type Horizontal

CNC or Not Normal

Voltage according to customer request

Power(W) 5.5

Dimension(L*W*H) 1800*2100*1870

Weight 2450

Certification CE ISO9001

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

Horizontal Knee-type Milling Machine XL6036

Specification	Unit	XL6030	XL6030A	XL6030B		XL6030C
Table size	mm	1270X300	1370X300	1270*300		1370*300
Table Travel (X/Y/Z)	mm	720/300/400	820/300/400	900/380/400		1000/380/400
Spindle taper	---	7:24 ISO40
Rapid speed of table (X/Y/Z)	mm/min	1000/1000/750
Table feed (X/Y/Z)	mm/min	Variable
T-slots(NO./Width/Pitch)	mm	3/14/80
Spindle speed range	r/min	12steps 35-1500
Distance between spindle nose and table surface	mm	75-475
Distance between spindle axis and column guideway	mm	155
Max. rotary angle of table	°	-
Main motor	kw	3
Torque of X/Y/Z axis AC servo motor	N.m	10
Overall size	mm	1720X1680X1730	1820X1680X1730		1720X1680X1730		1820X1680X1730
Net weight	kg	1500	1550		1550		1600

Rotary table can be ordered

Model	Table size	Max table travel - X/Y/Z	Max rotary angle of table	Distance between spindle center line and table surface
XL6130	1270X300	720/300/400	±45°	35-435
XL6130A	1370X300	820/300/400
XL6130B	1270X300	900/380/400
XL6130C	1370X300	1000/380/400
