Specifications
high speed drill and tapping machine1Pass the ISO9001:2008 certification
2High rigidity, capable of heavy load cutting
Z5140B high speed drill and tapping machine
Specification |
Unit |
Z5140B |
Z5140B-1 |
Z5150B |
Z5150B-1 |
Max drilling diameter |
mm |
40 |
50 |
||
Spindle taper |
|
MT4 |
MT5 |
||
Stroke of spindle quill |
mm |
250 |
|||
Spindle box travel(manual) |
mm |
200 |
|||
Spindle speed steps |
|
12 |
|||
Spindle speed range |
r.p.m |
31.5-1400 |
|||
Spindle feed steps |
|
9 |
|||
spindle feed range |
mm/r |
0.056-1.80 |
|||
Table size |
mm |
560 x 480 |
800 x 320 |
560 x 480 |
800 x 320 |
Longitudinal/cross travel |
mm |
- |
450/300 |
- |
450/300 |
Vertical travel |
mm |
300 |
|||
Max distance between spindle and table surface |
mm |
750 |
550 |
750 |
550 |
Main motor power |
kw |
3 |
|||
Overall size |
mm |
1090x905x2465 |
1300x1200x2465 |
1090x905x2465 |
1300x1200x2465 |
Net weight |
kg |
1250 |
1350 |
1250 |
1350 |
Standard Accessoriess:
1,Tree-jaw drill chuck
2,Drill chuck joint-bar
3,MT sleeve
Optional accessories can be added acoording to your requirement.
Cutting Speed Recommended
| Drilling | Tapping | |
| Hard Steel | 8-18 | 5-10 |
| Mild Steel | 14-26 | 8-12 |
| Cast Iron | 12-30 | 10-15 |
| Bronze | 30-50 | 12-20 |
| Aluminium and Brass | 40-60 | 14-25 |
