Z5150B-1 Vertical Directional Electric Drill 3000w
US$ 3,000 - 6,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Z5150B-1 Precision Vertical Drill MachineUS$ 3,000 - 6,000MOQ: 1 Set -
Z5140B-1 Square Column Drilling Machines for SaleUS$ 3,000 - 6,000MOQ: 1 Set
-
Z5140B-1 Precision Hole Drilling MachineUS$ 3,000 - 6,000MOQ: 1 Set
-
Z5140B-1 China Machine Drill Vertical TypeUS$ 3,000 - 6,000MOQ: 1 Set
-
Z5150B Cheap Manual Column Drill MachinesUS$ 3,000 - 6,000MOQ: 1 Set
Condition
New
CNC or Not
Normal
Place of Origin
Shandong, China
Brand Name
YOURONGXILI
Model Number
Z5150B-1
Voltage
380V
Power(W)
3000W
Dimension(L*W*H)
1300x1200x2465mm
Weight
1350KG
Certification
CE ISO
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Pass the ISO9001:2008 certificationHigh rigidity, capable of heavy load cutting
Z5150B-1 vertical directional electric drill 3000w
Specification |
Unit |
Z5140B |
Z5140B-1 |
Z5150B |
Z5150B-1 |
Max drilling diameter |
mm |
40 |
50 |
||
Spindle taper |
|
MT4 |
MT5 |
||
Stroke of spindle quill |
mm |
250 |
|||
Spindle box travel(manual) |
mm |
200 |
|||
Spindle speed steps |
|
12 |
|||
Spindle speed range |
r.p.m |
31.5-1400 |
|||
Spindle feed steps |
|
9 |
|||
spindle feed range |
mm/r |
0.056-1.80 |
|||
Table size |
mm |
560 x 480 |
800 x 320 |
560 x 480 |
800 x 320 |
Longitudinal/cross travel |
mm |
- |
450/300 |
- |
450/300 |
Vertical travel |
mm |
300 |
|||
Max distance between spindle and table surface |
mm |
750 |
550 |
750 |
550 |
Main motor power |
kw |
3 |
|||
Overall size |
mm |
1090x905x2465 |
1300x1200x2465 |
1090x905x2465 |
1300x1200x2465 |
Net weight |
kg |
1250 |
1350 |
1250 |
1350 |
Standard Accessoriess:
1,Tree-jaw drill chuck
2,Drill chuck joint-bar
3,MT sleeve
Optional accessories can be added acoording to your requirement.
