Open Two Roll Mill Machine

Open Two Roll Mill Machine thumbnail-1
Open Two Roll Mill Machine photo-1
US$ 5,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Open Mixing Mill
Place of Origin:
China
Contact Supplier Request Quote Chat Now
Shanghai Double Elephant Rubber & Plastic Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Open Mixing Mill
Place of Origin China
Brand Name Doubel elephants
Model Number X(S)K Series
Voltage 380V/50HZ
Power(W) lower
Dimension(L*W*H) Varies with diffrent Models
Weight 1-20 T
Certification CE, ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Lab open roll mill ,open mixing two roll mill ,two roll rubber mxing mixer

Open two roll mill machine

Open two roll mill machine

Open two roll mill machine

Open two roll mill machine

Open two roll mill machine

Open two roll mill machine

Open two roll mill machine

Product Description



Specification Type

Roller diaX length(MM)

Front roller linear velocity (M/MIN)

Velocity ratio of roller

Feeding quantity eachtime(KG)

Max. distance regulation (MM)

Motor Power (KW)

Overall dimension

(LxWxH)(MM)

X(S)K-160

160X320

8.95

01:01.4

1-20

4.5

5.5

1120X920X1295

X(S)K-250

250X620

15.2

01:01.1

10-15

8

18.5

3220X1500X1290

X(S)K-360

360X900

16.26

01:01.3

15-20

10

30

3920X1650X1725

X(S)K-400

400X1000

18.65

01:01.3

25-35

10

40

4380X1710X1880

X(S)K-450

450X1200

23.85

01:01.3

30-50

8

55

5050X1920X1870

X(S)K-560

560/510 X1530

27.61

01:01.3

50-60

12

95

5830X2300X2000

X(S)K-550

550X1500

27.175

01:01.3

50-65

15

90(110)

6040X2100X1625

XKY-660

660X2130

32.45

01:01.1

165KG

15

180

7450X3660X2080

XKR-660

660X2130

28.6

01:01.2

165KG

15

245

7465X3660X2080

Features:
1) The mixer is mainly applicable for both natural and synthetic rubber processing: thermal mixing of batches and finish squashing
2) Also it can be used for plastic industry and pigment industry as subsidiary application (PVC)
Company Information

COMPANY INFORMATION



Shanghai double elephants rubber and plastic machinery co., LTD., founded in 1994, specializing in the production and distribution group of companies affiliated factory production of rubber and plastic machinery, PVC film, artificial leather In addition, we also canaccording to user requirements design and manufacture non-standard equipment.We export to more than 40 countries and regions, deeply user high praise.

EXHIBITION

Open two roll mill machine

OUR EQUIPMENT

Open two roll mill machine

OUR CUSTOMER

Open two roll mill machine



CERTIFICATE OF HONOR

SALES NETWORK

Open two roll mill machine





Our Services

GUARANTEE & AFTER-SALE SERVICE

1,One year guarantee for whole machine except tubes

2,24 hours technical support by mail

3,service station in your country, quick response
