Layers Circuit Board, Number of Layers PCB, Number of Layers PCBA Assembly

Name: Layers Circuit Board, Number of Layers PCB, Number of Layers PCBA Assembly
Brand: MOKO
Availability: InStock

FOB Price

US$ 0.1 - 11 / Piece

1 Piece(Min. Order)

Port Shenzhen.Hongkong
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	MOKO
Model Number	MK50630BC	Base Material	FR4, ALU, PI, CEM
Copper Thickness	0.5OZ to 5OZ	Board Thickness	1.6mm, 1.0/ 2.0 mm
Min. Hole Size	0.25mm	Min. Line Width	0.075mm
Min. Line Spacing	0.075mm	Surface Finishing	HASL, OSP, ENIG

Packaging Details

Anti-static package with high quality carton box

Product Description

Layers Circuit Board, Number of Layers PCB, Number of Layers PCBA Assembly

MOKO services:

- Contract Manufacturing

- Engineering Services

- PCB Fabrication

- Component sourcing

- PCB assembly

- Function test (for free)

- Plastics and Molds

MOKO advantages:

- ISO9001: 2008 certificates

- UL and ROHS certificates

- PCBA free function test

- PCBA with 2 years warranty

- 10 years producing experience

- 8 SMT lines and 4 Thru-hole lines

- 400 workers

Orientronic PCB assembly Equipment:

- SMT Machine: SIEMENS SIPLACE D1/D2 / SIEMENS SIPLACE S20/F4

- Reflow Oven: FolunGwin FL-RX860

- Wave Soldering Machine: FolunGwin ADS300

- Automated Optical Inspection (AOI): Aleader ALD-H-350B

- Fully Automatic SMT Stencil Printer: FolunGwin Win-5

Technical Support:

- Professional Surface-mounting and Through-hole soldering Technology

- Various sizes like 1206,0805,0603 components SMT technology

- ICT(In Circuit Test),FCT(Functional Circuit Test) technology.

- PCB Board Assembly With UL,CE,FCC,Rohs Approval

- Nitrogen gas reflow soldering technology for SMT.

- High Standard SMT&Solder Assembly Line

- High density interconnected board placement technology capacity.

PCB Capacities and Technical Specification

Order Quantity	1-500,000
Layer	1,2,4,6,upto 18 layer
Material	FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc
PCB type	Rigid,flexible,rigid-flexible
Shape	Any shape: Rectangular,round,slots,cutouts,complex,irregular
Max PCB dimensions	20inch20inch or 500mm500mm
Thickness	0.2~4.0mm, Flex 0.01~0.25''
Thickness tolerance	± 10%
Copper thickness	0.5-4 oz
Copper thickness tolerance	± 0.25oz
Surface finish	HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc
Solder mask	Green, red,white,yellow,blue,black, Double-sided
Silk screen	White,yellow,black,or negative, Double-sided or single-sided
Silk screen min line width	0.006'' or 0.15mm
Min drill hole diameter	0.01'',0.25mm.or 10 mil
Min trace/gap	0.075mm or 3mil
PCB cutting	Shear,V-score,tab-routed

PCBA Capabilities

Turnkey PCBA	PCB+components sourcing+assembly+package
Assembly details	SMT and Thru-hole, ISO SMT and DIP lines
Lead Time	Prototype: 15 work days. Mass order: 20~25 work days
Testing on products	Flying Probe Test, X-ray Inspection, AOI Test, Functional test
Quantity	Min quantity: 1pcs. Prototype, small order, mass order, all OK
Files needed	PCB: Gerber files(CAM, PCB, PCBDOC)
	Components: Bill of Materials(BOM list)
	Assembly: Pick-N-Place file
PCB Panel Size	Min size: 0.250.25 inches(66mm)
PCB Panel Size	Max size: 2020 inches(500500mm)
PCB Solder Type	Water Soluble Solder Paste, RoHS lead free
Components details	Passive Down to 0201 size
	BGA and VFBGA
	Leadless Chip Carriers/CSP
	Double-sided SMT Assembly
	Fine Pitch to 0.8mils
	BGA Repair and Reball
	Part Removal and Replacement
Component package	Cut Tape,Tube,Reels,Loose Parts
PCB assembly process	Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing

MOKO Made Products:

Certificates:

Company Profile

Shenzhen Moko Technology Ltd.

MOKO TECHNOLOGY LTD is an expert at PCB and PCBA manufacture, based in Shenzhen, Guangdong, China. We are specialized in manufacturing Single-Sided Boards, Double-Sided Boards and multilayer PCB. We are honored as the excellent supplier of many companies all around this world. We can offer all kinds of services including PCB and PCB assembly sample orders and batch orders. We have got the ISO9001:2000, ISO14001, and UL RoHS certifications. Now our PCB daily capacity reaches 1000 square meters, and PCB assembly can reach 100,000,000 units per month. We deeply believe that our good service and experience will completely meet you need. Integrity, value and innovation are the forces that drive our success. We are the smart choice for you and the trusted source at the center of your deal. Welcome the win-win situation together.
