Shenzhen PCB board PCB circuit board fast sample and fast mass order
- 300000 Square Meter / Square Meters per Month
- SZ/HK
- T/T L/C D/P D/A Credit Card PayPal
- PCB board CNC/ Circuit board V cut/ printed pcb circuit board panels
- telivision tv pcb board
- electronic printed circuit boards
- Green Solder Mask Double Sided Peelable Mask PCB Fabrication
- Mask Immersion Gold Double Sided Peelable Mask PCB Fabrication
- 1-12layer lead free electronic pcb and assembly pcb supplier
Product Details
Place of Origin: | Guangdong, China | Brand Name: | MOKO | Model Number: | MK50413BC13 |
Base Material: | FR4 | Copper Thickness: | 1oz | Board Thickness: | 1.6mm |
Min. Hole Size: | 0.25mm | Min. Line Width: | 0.075mm | Min. Line Spacing: | 0.075mm |
Surface Finishing: | HASL |
Packaging Details
Anti-static package with high quality carton box
Product Description
Shenzhen PCB board PCB circuit board fast sample and fast mass order
- PCB circuit board fabrication
- PCB circuit board E-test
- PCB board fast delivery time
- PCB board sample or mass production welcomed
- Certificates: ISO9001:2008, CE, ROHS, UL
Function and Specification:
1 | Layers | Single Sided,2 to 18 Layer |
2 | Board material type | FR4,CEM-1,CEM-3,ceramic substrate board, aluminum based board, high-Tg, Rogers and more |
3 | Compound material lamination | 4 to 6 layers |
4 | Maximum dimension | 610 x 1,100mm |
5 | Dimension tolerance | ±0.13mm |
6 | Board thickness coverage | 0.2 to 6.00mm |
7 | Board thickness tolerance | ±10% |
8 | DK thickness | 0.076 to 6.00mm |
9 | Minimum line width | 0.10mm |
10 | Minimum line space | 0.10mm |
11 | Outer layer copper thickness | 8.75 to 175µm |
12 | Inner layer copper thickness | 17.5 to 175µm |
13 | Drilling hole diameter (mechanical drill) | 0.25 to 6.00mm |
14 | Finished hole diameter (mechanical drill) | 0.20 to 6.00mm |
15 | Hole diameter tolerance (mechanical drill) | 0.05mm |
16 | Hole position tolerance (mechanical drill) | 0.075mm |
17 | Laser drill hole size | 0.10mm |
18 | Board thickness and hole diameter ratio | 10:1 |
19 | Solder mask type | Green, Yellow, Black, Purple, Blue, White and Red |
20 | Minimum solder mask | Ø0.10mm |
21 | Minimum size of solder mask separation ring | 0.05mm |
22 | Solder mask oil plug hole diameter | 0.25 to 0.60mm |
23 | Impedance control tolerance | ±10% |
24 | Surface finish | Hot air level, ENIG, immersion silver, gold plating, immersion tin and gold finger |
Company Profile
MOKO TECHNOLOGY LTD is an expert at PCB and PCBA manufacture, based in Shenzhen, Guangdong, China. We are specialized in manufacturing Single-Sided Boards, Double-Sided Boards and multilayer PCB.
We are honored as the excellent supplier of many companies all around this world. We can offer all kinds of services including PCB and PCB assembly sample orders and batch orders.
We have got the ISO9001:2000, ISO14001, and UL RoHS certifications. Now our PCB daily capacity reaches 1000 square meters, and PCB assembly can reach 100,000,000 units per month.
We deeply believe that our good service and experience will completely meet you need. Integrity, value and innovation are the forces that drive our success. We are the smart choice for you and the trusted source at the center of your deal. Welcome the win-win situation together.
Contact Us
- Shenzhen Moko Technology Ltd.
- Contact nameRosina Zeng
- Phone86-755-23573370
- Address#401,U2,BLDG2,Guanghui Tech park Minqing Rd Longhua Shenzhen,Guangdong
