FR-4 Game Board Pcb

Name: FR-4 Game Board Pcb
Brand: Moko, Moko
SKU: 106349907
Availability: InStock

Shenzhen Moko Technology Ltd. Gold Verified Supplier

5Yrs

US$ 10 - 10,000 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Moko, Moko

Model Number:

MK-PCB072665

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Moko, Moko

Model Number MK-PCB072665

Number of Layers 6-Layer

Base Material FR-4

Copper Thickness 1oz, 1oz

Board Thickness 1.6mm

Min. Hole Size 0.4mm

Min. Line Width 3mil, 4mil

Min. Line Spacing 3mil, 4mil

Surface Finishing Hasl Immersion gold, hasl

Specifications

board
2.Fr-4 and 1.6mm
3.1-30 layer
4.Green solder mask with white legend
5.Hasl and Immersion Gold

game board

No.	items	Spec
1	Layers	1 to 24 layer
2	Max working panel area	457 x 610 mm
3	Min board thickness	4 layer: 0.40mm
		6 layer: 0.80mm
		8 layer: 1.00mm
		10 layer: 1.20mm
4	Min trace width	0.10mm
5	Min spacing	0.10mm
6	Min hole diameter	0.20mm
7	Min Copper thickness in hole	0.020mm
8	PTH size tolerance	±0.05mm
9	NPTH size tolerance	±0.025mm
10	Hole position tolerance	±0.05mm
11	Dimension tolerance	±0.1mm
12	Min solder mask dam	0.08mm
13	Insulation resistance	1E+12 Omega(normal condition)
14	Max Board thickness/Hole size Rate	10 : 1
15	Thermal shock endurance	288 3 times in 10sec
16	Max Board twist and wrap	≤0.7%
17	High Vlotage endurance	1.3KV/mm
18	Copper foil peel off endurance	1.4N/mm
19	Hardness of resist ink	≥6H
20	Flame resistance	94V-0
21	Impedance control	±5%
