High Quality Electronic Product Pcb

Layer

1,2,4 or 6,upto 18 layers

Material

FR4,CEM1,CEM3,Hight TG,FR4 Halogen Free,FR1,FR2

Order Quantity

1-500,000

Board shape

Rectangular,round,slots,cutouts,complex,irregular

Board type

Rigid,flexible,rigid-flexible

Board material

FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc

Board cutting

Shear,V-score,tab-routed

Board thickness

0.2~4.0mm,Flex 0.01~0.25''

Copper weight

1.0,1.5,2.0oz

Solder mask

Double-sided green LPI,Also support red,white,yellow,blue,black

Silk screen

Double-sided or single-sided in white,yellow,black,or negative

Silk screen min line width

0.006'' or 0.15mm

Max board dimensions

20inch*20inch or 500mm*500mm

Min drill hole diameter

0.01'',0.25mm.or 10 mils

Surface finish

HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc

Board thickness tolerance

± 10%

Copper weight tolerance

± 0.25oz

Minimal slot width

0.12'',3.0mm,or 120mils

V-score depth

20-25% of board thickness

Plated through holes

Yes

Sink holes

Yes

Design file format

Gerber RS-274X,274D,Eagle and AutoCAD'S DXF,DWG

Quantity

Prototype&Low Volume PCB Assembly,from 1 Board to 250,is for specialty,but we can handle orders up to 1000

Type of Assembly

SMT and Thru-hole

Solder Type

Water Soluble Solder Paste,Leaded and Lead-Free

Components

Passives Down to 0201 Size

BGA and VFBGA

Leadless Chip Carries/CSP

Double-Sided SMT Assembly

Fine Pitch to 08 Mils

BGA Repair and Reball

Part Removal and Replacement-Same Day Service

Bare Board Size

Smallest:0.25x0.25 Inches

Largest:20x20 Inches

File Formats

Bill of Materials

Gerber Files

Pick-N-Place File(XYRS)

Type of Service

Turn-Key,Partial Turn-Key or Consignment

Component Packaging

Cut Tape

Tube

Reels

Loose Parts

Turn Time

Same Day Service to 15 day service

Testing

Flying Probe test

XRAY Inspection AOI Test

Single,Double sided

Four layer

Six layer

Above eight layer

HDI

Sample lead time(Normal)

5-6

6-7

7-8

10-12

15-20

Sample lead time(Fastest)

48 to 72 hours

5

6

6-7

12

Mass production

lead time(First batch)

7-9

10-12

13-15

16

20

PCB Assembly

PCB Fab+Components Sourcing+PCBA=15 days
