4 layer green solder mask pcb manufacturer aircraft electronic components PCBA

Name: 4 layer green solder mask pcb manufacturer aircraft electronic components PCBA
Brand: MOKO
Price: USD $1 - 10 / Piece

FOB Price

USD $1 - $10 / Piece

1 Piece(Min.Order)

Supply Ability 1000 Square Meter / Square Meters per Month
Port Shenzhen or Hong Komg
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	MOKO	Model Number:	MK51231BE01
Number of Layers:	4-Layer	Base Material:	FR-4	Copper Thickness:	1oz
Board Thickness:	1.6mm	Min. Hole Size:	0.25mm	Min. Line Width:	0.1mm
Min. Line Spacing:	0.1mm	Surface Finishing:	HASL

Packaging Details

Inner packing :Vacuum Package Outer packing:Standard Carton

Product Description

4 layer green solder mask pcb manufacturer aircraft electronic components PCBA

PCB Technical Specification

Number of Layer	1,2,4 or 6,upto 18 layer
Order Quantity	1 to 50,000
Board Shape	Retangular,round,slots,cutouts,complex,irregular
Board Type	Rigid, Flexible, Rigid-flexible
Board Material	FR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc.
Board Cutting	Shear,V-score,Tab-routed
Board Thickness	0.2-4.0mm, Flex 0.01-0.25mm
Copper Weight	1.0, 1.5, 2.0 oz
Solder Mask	Double-sided green LPI,Also support Red,White,Yellow,Blue,Black
Silk Screen	Double-sided or single-sided in white,yellow,black,or negative
Silk Screen Min Line Width	0.006'' or 0.15mm
Max Board Dimensions	20 inch20inch or 500mm500mm
Min Trace/Gap	0.10mm, or 4mils
Min Drill Hole Diameter	0.01'',0.25mm, or 10mils
Surface Finish	HASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc.
Board Thickness Tolerance	±10%
Copper Weight Tolerance	± 0.25 oz
Minimal Slot Width	0.12'', 3.0mm, or 120mils
V-Score Depth	20-25% of board thickness
Design File Formate	Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG

PCBA Capabilities

Quantity	Prototype&Low Volume PCB Assembly,from 1 Board to 250,is specialty,or up to 1000
Type of Assembly	SMT,Thru-hole
Solder Type	Water Soluble Solder Paste,Leaded and Lead-Free
Components	Passive Down to 0201 size BGA and VFBGA Leadless Chip Carriers/CSP Double-sided SMT Assembly Fine Pitch to 0.8mils BGA Repair and Reball Part Removal and Replacement
Bare Board Size	Smallest:0.250.25 inches Largest:2020 inches
File Formate	Bill of Materials Gerber files Pick-N-Place file
Types of Service	Turn-key,partial turn-key or consignment
Component packaging	Cut Tape,Tube,Reels,Loose Parts
Turn Time	Same day service to 15 days service
Testing	Flying Probe Test,X-ray Inspection AOI Test
PCB assembly process	Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing

Technical requirement for pcb&pcb assembly:

1. Professional Surface-mounting and Through-hole soldering Technology
2. Various sizes like 1206,0805,0603 components SMT technology
3.ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4.PCB Assembly With UL,CE,FCC,Rohs Approval
5.Nitrogen gas reflow soldering technology for SMT.
6.High Standard SMT&Solder Assembly Line
7. High density interconnected board placement technology capacity.

Quotation requirement for pcb&pcb assembly:

1. PCB gerber file

2. BOM list for PCBA

3. Sample of PCB and PCBA

4.Test method for PCBA

PCB Assembly Production Process

PCB Assembly plastic enclosures

Lead time:

PCB	Single/double side	4 layer	6 layer	Above 8 layer	HDI
Sample lead time(Normal)	5-6	6-7	7-8	10-12	15-20
Sample lead time(Fastest)	48-72 hours	5	6	6-7	12
Mass production lead time(First batch)	7-9	10-12	13-15	16	20
PCB Assembly	PCB Fab+Components Sourcing+PCBA=20 days

PCB Assembly relating product show

Packaging & Shipping

Our Services

1.PCB

2.Component service

3.PCB Assembly

4.PCBA testing

5. PCB Assembly with Enclosure

Our Advantage:

PCB quoted online

Original ICs and compoennts from stock

High quality PCBA and competitive price

100% PCBA function testing

Warranty: 2 Years

Shortly lead time: PCB :4-9 days,PCBA:20-25days

Certificate:UL,ROHS,CE,ISO9001,ISO14001

PCBA OEM service with more than 10 years experience

PCB Sample Cost:

Notes:The Following Cost for the Special Samples Cost, the cost only for pcb cost, the film cost and tool cost will be based on the pcb file you provided.quantity below 10pcs. (Unit:mm)

1-2 Layer	4 LAYER	6 Layer	8 Layer
Below 3*3 5.3USD	Below 5*5 67.0USD	Below 5*5 167.0USD	Below 5*5 317.0
Below 5*5 8.8USD	Below 10*10 84.0USD	Below 10*10 184USD	Below 10*10 350.2USD
Below 10*10 $17.1

Batch Quantity Cost:

Notes: The Following Cost don't include the Engineer Cost.

PCB Thickness(mm)	2 Layer(/M^2)	4 Layer(/M^2)	6 Layer(/ M^2)	8 Layer(/M^2)
0.4~0.8	65.3USD	133.3USD
1.0~1.2	65.5USD	138.3USD	208.5USD	283.5USD
1.6	67.0USD	142.0USD	217.0USD	300.2USD
2.0	70.2USD	150.3USD	300.0USD	333.5USD
2.4	100.2USD	158.5USD	367.0USD	366.8USD
3.0	108.2USD	200.2USD	400.3USD	433.5USD
