Welding Generator
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
KOOP
Model Number:
KDF6700WE
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
KOOP
Model Number
KDF6700WE
Output Type
AC Single Phase
Speed
3000/3600rpm
Frequency
50HZ/60HZ
Rated Power
3KW
Rated Voltage
220V
Rated Current
180A
| Model | KDF6700WE | |||
| Rated frequency (Hz) | 50 | 60 | ||
| Rated voltage (V) | 240 | 240 | ||
| Rated current (A) | 9.2 | 9.5 | ||
| Rated output power (KVA) | 4.2 | 4.5 | ||
| Rated rotation speed (rpm) | 3000 | 3600 | ||
| Welding voltage without load (V) | 55-65 | |||
| Rated current (A) | 160 | |||
| Work voltage (V) | 26 | |||
| Current regulation range (A) | 50-180 | |||
| Welding load continuous ratio | 60% | |||
| Power factor cosφ | 1 | |||
| Phase number | Single phase | |||
| Noise level dB(A)@7m (zero load-full load) | 74-79 | |||
| Net weight [kg(lbs)] | 154 (338) | |||
| Overall dimension [mm(in)](L×W×H) | 775×485×580 (30.51×19.09×22.83) | |||
| Structure model | Open-frame | |||
| Engine model | KD186FAE | |||
| Engine type | 1-cyliner, 4-stroke, air-coolde, vertical, diesel engine | |||
| Displacement [cm³(Cu-in)] | 418 (25.51) | |||
| Compression ratio | 19:01 | |||
| Reted power [KW(Hp)/rpm] | 6.3 (8.6)/3600 | |||
| Rated rotation speed (rpm) | 3000/3600 | |||
| T.C.L. | No | |||
| Spark plug | 12V electric starter | |||
| Starting system | Electric starting | |||
| Rotation direction (view from flywheel) | Clockwise | |||
| Fuel type | 0# (summer), -10# (winter) diesel oil | |||
| Lube | CD or bettet than CD | |||
| Low oil presssure alarm system | With | |||
