Specification
1.Power Supply: AC220V±10V ,50Hz / AC110V±10V ,60Hz
2.DC Motor: 100w/24v
3.Temperature: -15 °-60°
4.Humidity: <95%, without concretion
5.Passage Width: <=600mm
6.Passing Speed: 30 persons/min (Normal open),
20 persons/min (Normal close)
7.Input Interface: +12V electrical signal or impulse signal with width more than 100ms, drive current >10mA
8.Communication Interface: RS485 (Distance: <=1200m)
9.Flap barrier Arm Open and Close Time Length: 1s
10.Passage Width: 600mm (Our standard) <=900mm (each unit)
11. Material: Housing - 304 stainless steel
Features and specifications:
1.Unique incomplete wheel transmission is adopted to make flap barriers held or unheld in zero position more accurate and reliable.
2.Running stable, little noise and no mechanical impact
3.Self-checking-power-on function, if power on, flap barrier will auto get to be held.
4.Flap barrier will auto alarm when some unauthoried person gets in.
5.Various working means can be set in the control panel menu, namely: bi-direction card reading passing, or one direction card reading passing and another passing limits, or one direction card reading passing and another free passing, etc.
6.If power off, arm will open automatically while power on late.
7.It is with RS485 connection for far control arm up and down to satisfy the special needs or fire control requirements.
8.It is with standard electrical interface to connect various kinds of readers and writers for easy integration and also computer far control and management can be realized by computer.
9.Passing direction will be shown by LED and passengers will know which direction is allowed to pass.
10.Re-position function. After card reading, if passenger not through within the specific time, system will auto cancel passing right for this time and the limit passing time length can be set.
11. Optional:
1) Counter and counter display
2) Access controller or card reader
3) Key by-pass
