white paper rewinder slitter
Main Technical Parameters
Name |
slitting machine |
|
Item number |
JZ-2000N |
Suitable material |
LDPE or HDPE film |
Slitting width |
500-2000mm |
Mother roller weight |
150-300kg |
Max.dia of un-winder |
700mm |
Max.dia of re-winder |
500mm |
Sub roller weight |
10-100kg |
Mother roller paper core diameter |
76mm |
Sub roller paper core diameter |
76mm or other size |
Speed |
0-300m/min |
Motor power |
3KW+Inverter 3.7KW |
Feature
slitting machine:
slitting machine is to use a traditional control scheme a large-volume motor to drive the retractable shaft, the retractable reel plus a magnetic clutch, clutch by adjusting the magnetic current to control the resistance they have to control the material surface tension.
slitting machine is a wide-format paper or film will be cut into multiple narrow the mechanical equipment, commonly used in film, paper making machinery and printing and packaging machinery.
Slitting machine design for slitting and rewinding 2 meter width of the film.
1- Simple design, easy operation, high speed.
2- Adopt the air shaft for both un-winder and re-winder. (2" and 3" for the rewinder is OK).
3- The un-winder also fit for 2 rolls by 1 meter width of the film. It can working at the same time.
