Specifications
pellet water heating stove1.boiler is 52L
2.remote control design
3.automatic ignition system
pellet water heating stove
| Output Power | 24kw | ||
| Heat area(m3) | 435 | ||
| Efficiency | 95% | ||
| Rating Power Min/Max (KW) | 14KW/24KW | ||
| Rating Power Water Min/Max (KW) | 10KW/19KW | ||
| Automatic burning time min/max (h) | 8H/14H | ||
| Consumption for pellet min/max (KG/H) | 2.8/5(KG/H) | ||
| Temperature of the smoke output Max/Min(°C) | 95/80 | ||
| Rating Valtage and Frequency(v/hz) | 230V/50HZ | ||
| Max water pressure(bar) | 1.5Bar | ||
| Electronic Comsuption Max(w/h) | 400W/H | ||
| Smoke outlet /intlet pipe (ø mm) | 80mm/50mm | ||
| Pellet tank capacity (kg) | 40kg | ||
| ΦAir outlet pipe(mm) | 80mm | ||
| Working power input (W) | 70W | ||
| Flue draught pressure(pa) | 0.1-15 | ||
| Water tank Capacity | 52L | ||
| Product Size(MM) | 630*1278*720 | ||
| Carton Size(MM) | 705*780*1455 | ||
Features of 24KW automatical hydro stove SMT-33F3
1. Outside: steel-powder coating.
2. Inside: monobloc steel structure, hand welded, heat-resistant up to 1200°C with high temperature paint.
3. Door: carbon steel, high temperature resistant, with ceramic-glass.
4.Removable ash box: it collects the ash fallen through the holes in the brazier.
5. Glass-self cleaning: designing wind to blow ash from the glass keeps the glass always cleaning.
6.LCD control panel: it is placed on the upper side of the stove, simple and easy to be used. It is possible to plan the weekly switching on and off of the stove (week-end included).
7.Thermostat: The stove can keep the room's temperature stably. The temperature can be selected by users both on the panel and remote control, showing on the display.
8. Four steps power setting: it is up to your need, which also shows on the display.
9. Smoke outlet: ø 80 mm, inlet ø 50 mm.
10. Electrical supply: 230V-50Hz-1Ph. 120V-60HZ, 100V-50HZ
11. Remote Control: it is helpful to have the functions of on and off; Power low or high; temperature low or high; Auto or manual in your hands within 10 meters scope.
12. Automatically clean the dust inside the Burner: it is solved the problem of clogging to the burner when the ash value of biomass pellet is over 2%. Reduce the frequency of your cleaning times
SMT-33F3,packed in carton box.carton size:705*780*1455MM
20'GP container:34pcs.
Packing Show:
SMT-33F3,packed in carton box.carton size:705*780*1455MM
20'GP container:34pcs.
1.Sample order is welcomed
2.OEM is accepted
of delivery can be assured,within 25 days after order confirmed
Hefei Smartmak Co., LTD,founded in 2005,is a professional manufacturer for pellet stoves in China.
It is a professional factory which is engaging in producing and selling healthy & environmental pellet stove, pellet boiler, wood pellet stove, as well as other series.
