Help CenterDL1000 Inverted Vertical Bolt Making Machine
Related Products
-
Aluminum Roller Drawing Machine Production LineUS$ 10,000 - 50,000MOQ: 1 Set -
Wet Wire Drawing Machine LT11/450/nail Making Machine/wire Coiler MachineUS$ 1,000 - 20,000MOQ: 1 Set
-
Professional Turnover Wet Wire Drawing Machine/descaling Machine/wire Coiler Machine/butt Welding MachineUS$ 1,000 - 20,000MOQ: 1 Set
-
High Speed Carbon Steel Wire Drawing Machine/descaling Machine/wire Coiler Machine/nail Wire Making MachineUS$ 1,000 - 20,000MOQ: 1 Set
-
New Design Good Quality Carbon Steel Wire Drawing Machine/nail Wire Making MachineUS$ 1,000 - 20,000MOQ: 1 Set
Specifications
Use: WirePlace of Origin: Jiangsu, China
Brand Name: wandeshun
Model Number: DL1000
Specifications
Max inlet: 40mm
For low, medium, stainless steel wire
Suitable for fastner industrial and supermarket shelf
20% compression
Inverted vertical wire drawing machine
Description
Inverted Vertical Drawing Machine is developed for the non-slip drawing of medium&low carrbon steel wire, special shaped steel wire and nonferrous metals with thick & medium diameters.
It is especislly suitable for the drawing of medium & low carbon steel wire in standard parts and supermaket shelf industriy.
The maximum inlet diameter can reach 40mm and diameter of capstan is 550-1400mm.
Transmission part of the system can apply cycloidal speed reducer, harden gear surface reducer or rocker reducer. Its electric system applies international famous brand frequency converter with performance.
Features of the equipment
1. It is applicable for continuous production process of coil with heavy charing box.
2. Easy operation and reliable control enables safe production and conveninent maintenance.
3. Application of 3-phase AC variable-frequency speed adjustment realizes smooth stepless speed regulation and saves more than 30% electric power.
Main Parameters
Items |
Unit |
Type |
Diameter of Capstan |
mm |
Φ550-Φ1400 |
Max diameter of inlet wire |
mm |
Φ40 |
Intensity of material |
M pa |
≤1200 |
Compression rate |
% |
15-30 |
Wire drawing line |
m/s |
2.5 |
Single motor power |
Kw |
11-110 |
Send Inquiry to This Supplier
