CNC Thick Steel Cutting Machine Beam Shearing Machine
US$ 1 - 12,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
Baide
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
QC11K CNC Thick Steel Plate Shearing Machine Guillotine Shear Power ShearUS$ 1 - 12,000MOQ: 1 Set -
Guillotine Hydraulic CNC Cutting MachineUS$ 1 - 12,000MOQ: 1 Set
-
QC11K CNC Thick Steel Plate Shearing Machine Guillotine Shear Metal Cnc Hydraulic GuillotineUS$ 1 - 12,000MOQ: 1 Set
-
Metal Cnc Hydraulic GuillotineUS$ 1 - 12,000MOQ: 1 Set
-
QC11K CNC Guillotine Shear Guillotine Metal Cutting MachineUS$ 1 - 12,000MOQ: 1 Set
Condition
New
Place of Origin
Anhui, China
Brand Name
Baide
Model Number
QC11K
Voltage
380V
Rated Power
1500v
Dimension(L*W*H)
4450*2000*2600
Weight
8.5Ton
Certification
CE
Warranty
1 year
After-sales Service Provided
Overseas third-party support available
CNC thick steel plate shearing machine
Technical parameter
| No. | Specification | Unit | ||
| 1 | Cutting thickness | 10 | mm | |
| 2 | Cutting width | 4000 | mm | |
| 3 | Cutting plate strength | 450 | N/mm2 | |
| 4 | Cutting angle | 0.5°-2° | ||
| 5 | Stroke times | 6-10 | min-1 | |
| 6 | Column distance | 4250 | mm | |
| 7 | Blade length | 4100 | mm | |
| 8 | The height between worktable and ground | 850 | mm | |
| 9 | Back gauge range | 20-600 | mm | |
| 10 | Main motor | Model | Y200L1-6 | |
| Power | 15 | KW | ||
| Turn numbers | 1440 | rpm | ||
| 11 | Gear pump | Model | NT2-32F | |
| Flow | 32 | L/min | ||
| Pressure | 32 | MPa | ||
| 12 | Hydraulic system max work pressure | 25 | MPa | |
| 13 | Overall dimension | Length | 4450 | mm |
| Width | 2000 | mm | ||
| Height | 2600 | mm | ||
