Discription
1.The frame is entirely welded with steel plates,machined integrally to ensure precision
2.Hydraulic top-drive, stepless pressure adjustment and high quality sealing rings imported from overseas
3.Mechnical Synchronous mechanism and the complex compensation are designed
4.The stroke and distance of the backgauge is adjusted by the motor and manual fine tuning, the ajustment is displayed by digital meters.
5.Inch,single cotinuous operation mod designed for the machine, dwell time was controlled by time relays
6.Safe fence and power break
Parameters:
NO. |
Item |
Valve |
Unit |
Remarks |
1 |
Nominal pressure |
1250 |
KN |
|
2 |
width |
3200 |
mm |
|
3 |
Distance between uprights |
2600 |
mm |
|
4 |
stokes |
130 |
mm |
|
5 |
Open height |
390 |
mm |
|
6 |
Throat depth |
320 |
mm |
|
7 |
Length of working table |
3200 |
mm |
|
8 |
Running speed |
100 |
mm/s |
|
9 |
Working speed |
10 |
mm/s |
|
10 |
Returning speed |
70 |
mm/s |
|
11 |
Main power |
7.5 |
KW |
|
12 |
Length |
3350 |
mm |
|
13 |
Width |
1350 |
mm |
Not include front support |
14 |
Height |
2420 |
mm |
|
15 |
Weight |
7000 |
kgs |
|
16 |
Axes |
2 |
|
X,Y |
Main confiuration
1. Japan NOK hydraulic seals is used
2.USA OMEGA hydraulic valves is standard for you, Germany BOSCH REXROTH is option
3.Motorized-adjusting device of back gauge and rams stroke,
4.Siemens and Schneider electric parts.
5.Inner gear pump, with good quality and lower noise.
Main features
1.Steel-welded construction, vibration to eliminate stress, with high strength and good rigidity.
2.Hydraulic top-drive, steadiness and reliability.
3.Mechanical stop, steel torsion bar to maintain synchronization, high precision.
4.Motorized-adjusting device of back gauge and rams stroke
5.Deflection compensation unit installed on the top die.
6.Travel limit protection. Full machine guarding with safety interlock.
Usage
Upper and lower Tool
Standard and optional equipment
CE certificate
