hydraulic guillotine steel plate
How to contact us ?
Send your Inquiry Details in the Below, Click "Send" Now!
Main features:
1. Holistic welding structure
2. Hydraulic-driven upper blade carrier moving downward and linearly
3. Both the upper and lower blades are rectangular, and the blade clearance can be adjusted manually or electrically rapidly.
4. Time relay controls shearing stroke and shearing angles are adjusted electrically
5. The forward and backward movement of back gauge is motorized and indicated by a digital display, while fine adjustments are also available
6. All major electrical and hydraulic elements are assembled with high grade international brands
7. Pneumatic back support is optional
Technical data:
we have all kinds of shearing machine, just feel free to get more information!
Specification |
Max. shearing thickness |
Max. shearing width |
Shearing angle |
Ram strokes |
Back gauge range |
Motor power |
mm |
mm |
° |
n/min |
mm |
kw |
|
QC11Y-6x2500 |
6 |
2500 |
1°30 |
17 |
20-600 |
7.5 |
QC11Y-6x3200 |
6 |
3200 |
1°30 |
14 |
20-600 |
7.5 |
QC11Y-6x4000 |
6 |
4000 |
1°30 |
10 |
20-600 |
7.5 |
QC11Y-8x2500 |
8 |
2500 |
1°30 |
14 |
20-600 |
11 |
QC11Y-8x3200 |
8 |
3200 |
2° |
10 |
20-600 |
11 |
QC11Y-8x4000 |
8 |
4000 |
2° |
8 |
20-600 |
11 |
QC11Y-10x2500 |
10 |
2500 |
1°30 |
10 |
20-600 |
11 |
QC11Y-10x3200 |
10 |
3200 |
2° |
10 |
20-600 |
11 |
QC11Y-10x4000 |
10 |
4000 |
2° |
12 |
20-600 |
11 |
QC11Y-12x2500 |
12 |
2500 |
2° |
10 |
20-800 |
15 |
QC11Y-12x3200 |
12 |
3200 |
2° |
10 |
20-800 |
22 |
QC11Y-25x3200 |
25 |
3200 |
3° |
5 |
20-800 |
37 |
Control system:
other NC and CNC control system for optional
How to get a accurate quotation from us ?
1,tell us metal thickness.
2,tell us metal widthness.
How to repair&maintain our machine ?
Generally,the hydraulic machine is not easy to break.even though the problem occur,it is small problem.
we can solve it through email and video.
what policy for broken parts?
within one year,we offer free parts.
if beyond one year,you need to buy by factory cost.
Why choose Us?
1.Reply your inquire in 24 hours
2.Experienced staffs answer all your query in fluent English
3.Exclusive and unique solution can be provided to our customer by our well trained and professional engineers and staffs
4.Customerized design is available,OEM/ODM are welcomed
5.Warmly welcome your visit in our company if avaiable
