Specifications
Bicycle testing machineThis tester is suitable to test bike's riding and brakes performance test.
Bicycle testing machine
* THIS MACHINE OFFER ONE SET OF PC HARDWARE AND OPERATION SOFTWARE.
* THIS TESTER IS SUITABLE TO TEST BKIE’S RIDING TEST & BRAKES PERFORMANCE TEST. THE TEST IS FORMED BY TWO ROLLERS WITH VARIED DIAMETER AND FOLLOW SPEC TO INSTALL JUMP PLATES AT BIKE’S SEAT TUBE, PEDALS, HANDLEBAR, LUGGAGE CARRIERS, WITH LOAD SET TO THIS TESTER. ADJUST THE DISTANCE BETWEEN FRONT AND REAR WHEELS BASE ON THE STANDARD FOR COMPLETE CYCLES, CONSTANTLY ROATE THE WHEELS BY 7~24 km/hr AND THE BKIE IS SUPPOSED TO MAINTAIN ITS NORMAL FUNCTION , NO PART DAMAGE OR CRACK IS FOUND. FOR BRAKE TEST, FOLLOW THE SPEC-SPECIFIED ROLLER’S FRICTION COEFFICIENT, WIND SPEED, RIDE-WAY SLOPE AND WATER-SPRAY AMOUNT OF LOADED BRAKE & HANDLEBARS TO TEST THE PERFORMANCE.
* THIS MACHINE IS DESIGNED AS STANDARD EN 14764 / EN 14765 / EN 14766 / EN 14781
Feature:
1. High-Intelligence Computer System :
Computer System
(1) Window XP Operation System, Nglish Version High Safety and Stability in Operation.
a. Computer operation system (Industrial computer).
b. HP Color inkjet printer
c. 19" LCD color monitor .
(2) Interface card.
Control System :
(1). Auto-Control Setting
(2). Abnormal-Detection Abnormal-Detection And Shutdown
Control Ability :
(1). Lot number table: can print test data in the same lot together.
(2). Report table preview ability.
(3). Correspond user’s demand to edit various tables.
(4). Provide the maximum, minimum & mean values in data table.
Software Function:
(1). Bear the “amplification auto range” ability; program would dynamically adjust the signal zoom-in rate along with the load status.
(2). 16-bit analog/digital converter, the maximum, resolution can be 1/20000.
(3). Force unit: provide interchangeable kg, g, lb, n, kn and ton units
(4). Digit display: can change up to three digits after decimal according to user’s setting.
Graphics Displaying Ability:
(1). Have “Auto Scale” Ability To Display Graphics By The Best Fit Scale.
(2). Graphic Type Displayed: Load-Time Chart
(3). Zoom In: Can Select Spot Zone In A Chart And Enlarge It.
(4). Drag: Can Drag Graphic To Required Location.
(5). Coordinate Drag: Can Enlarge Graphic.
(6). Graphic Printout: Can Print Out The Enlarged Graphic.
File Save ability :
(1). Display Graphics and Data
(2). Cn Zoom In The Graphics Displayed.
(3). Use Database To Manage The Test Data
(4). Can Change Unit Applied In Existed File
Specification:
