Hydraulic cylinder with advantage widely used in agricultural machinery

Hydraulic cylinder with advantage widely used in agricultural machinery:

Advantages:

1.Cylinder Bore: Honing machining /boring /rolling;

2.Rod:Hard chrome plating;

3.Surface Treatment: Shot blasting for Anti-Corrosion Paint;

4.Customized supply,timely delivery;

5.One year warranty period

Mounting way:

1 Front and end of earring

2 head fixed with flange

3 end fixed with flange

4 vertical to axis foot type

5 middle fixed with pendulum shift

6 end with single earring

Price and technical solutions ,In order for you to get a better price and technical solutions.

Please provide the following required parameters:

1. bore diameter;

2. rod diameter;

3. stroke;

4. working pressure;

5. front and back end mount type;

6. using frequency;

7.Work Environment;

Certainly, you can provide drawing and product photos so that we can understand your meaning more conveniently, or you can also send us sample and we produce for you according to your sample.

WhatsApp:+86 18363062110

Skype: agnes-gao

Our factory has history about 20 years, which has strong technical force. Including 300 processing equipments, large machining center, large boring mills, grinding machines etc. We can design the technical drawing sheets and technical solution plans according to your requirement.
