Home > Products > Power Press > JH21 Pneumatic Power Press, C Type Single Crank Power Press

JH21 Pneumatic Power Press, C Type Single Crank Power Press

Name: JH21 Pneumatic Power Press, C Type Single Crank Power Press
Brand: BAIDE
Price: USD $1,000 - 50,000 / Piece

FOB Price

USD $1,000 - $50,000 / Piece

1 Piece(Min.Order)

Product Details

Condition:	New	CNC or Not:	Normal	Power Source:	Mechanical
Place of Origin:	Anhui, China	Brand Name:	BAIDE	Model Number:	JH21
Voltage:	220V/380V/240V/415V	Power(W):	5.5kw	Weight:	5400KGS
Dimension(LWH):	158012102520mm	Certification:	CE ISO SGS	Warranty:	2 Years
After-sales Service Provided:	Engineers available to service machinery overseas

Main parameters (Optional)

		JH21-80T
1	Nominal force	630KN
2	Stroke under nominal force	4mm
3	Ram stroke	120mm
4	Stroke time	70 times/min, 60-80 Variable
5	Max. mould height	300mm
6	Mould height adjustment	80mm
7	Distance from stroke surface to table	300mm
8	Working table dimension	900*580mm
9	Thickness of working table	110mm
10	Distance between columns	560mm
11	Motor power	5.5KW
12	Dimension	158012102520mm
13	Net weight	5400kg

Maanshan Baide CNC Machinery Co., Ltd.: Contact nameSisi Xu; Phone0086-0555-6762210; AddressIndustrial District, Xinshi
