Economical Glass Working Machine Cnc Engraving Machine for Door Glass

Economical Glass Working Machine Cnc Engraving Machine for Door Glass thumbnail-1
Economical Glass Working Machine Cnc Engraving Machine for Door Glass photo-1
US$ 10,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Engraving Machine / CNC Router
Place of Origin:
Zhejiang, China
Contact Supplier Request Quote Chat Now
Haining Lidu Glass Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Machine Type Engraving Machine / CNC Router
Place of Origin Zhejiang, China
Brand Name LIDU
Model Number LDKE2512
Voltage 380V
Power(W) 18Kw
Dimension(L*W*H) 2500X1200X155
Weight 6t
Certification Other, CE, ISO & CE
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

glass working machine
1.Stationary system
2.High processing speed
3.CNC system
4.CE certificate

Economical glass working machine cnc Engraving Machine for door glass

Economical glass working machine cnc Engraving Machine for door glass in the factory



Brief introduction of  glass working machine cnc Engraving Machine for door glass

This CNC Engraving Machine is a new equipment for glass deep processing. It adopts CAD system and is designed by several senior engineers together. It is widely used in notching and polishing in glass and mirror.

The whole processing procedure from pattern design to processing is controlled by computer. We can equip tool library and change tool system according to customers' requirements.

-------------------------------------------------------------------------------------------------------

Economical glass working machine cnc Engraving Machine for door glass

Delivery site of  glass working mahcine cnc Engraving Machine for door glass



Main features of  glass working machine cnc Engraving Machine for door glass

1.  Fast processing. The max. speed of the air knife of axis X can reach 60 m/min.
2.  Unique international pattern simulating function makes the processing patterns more visible, thus failure has been decreased greatly.

3.  Wide using range of grinding wheel: from Φ110 to Φ170, this is twice of the same products in China. The producing cost has been reduced greatly.

4.  Both Chinese & English interface. It is easy to learn and operate.

-------------------------------------------------------------------------------------------------------

Technical Parameters of glass working machine cnc Engraving Machine for door glass :



Model

LDKE2512

LDKE3016

LDKE3019

Table Size(mm)

2500×1200

3000×1600

3000×1900

Stroke of Axis x,y,z(mm)

2500×1200×155

3000×1600×155

3000×1900×155

Rotating Angle of Axis

0~360°

0~360°

0~360°

Allocating Accuracy(X,Y,Z)

0.01×0.02×0.01

0.01×0.02×0.01

0.01×0.02×0.01

Allocating Accuracy of Axis C

5’’

5’’

5’’

Repeatability(mm)

0.005×0.01×0.005

0.005×0.01×0.005

0.005×0.01×0.005

Axis C

2’’

2’’

2’’

Velocity(Axis X.Y)(m/min)

60

60

60

Speed of Axis Z(m/min)

30

30

30

Quantity of Knives (PCS)

10

10

10

Rotating Speed of Main Spindle Speed(rpm)

0-6000

0-6000

0-6000

CNC System

USA

USA

USA

Main Spindle Power(KW)

4

4

4

Max Width of Slot(mm)

30

30

30

Glass Thickness(mm)

3-30

3-30

3-30

Max.Diameter of Grinding Wheel(mm)

170

170

170

Total Power (kw)

18

21

22

Final product of glass working machine cnc engraving machine for door glass:

 Economical glass working machine cnc Engraving Machine for door glass

OUR SERVICE

 Your inquiry related to our product & price will be replied within 24hours.

 Well-trained & experienced staff are to answer all your inquiries in English of course.

 Working time: 9:00am - 6:00pm, Monday to Friday (UTC+8).

 OEM & ODM projects are highly welcomed. We have strong R&D team here to help.

 Your business relationship with us will be confidential to any third party.

 Good after-sale service offered, please get back if you got question.

 For more details, please feel free to contact us. We will be more than happy to help in anyway we can.

Operating system of glass working machine cnc engraving machine for door glass:

Economical glass working machine cnc Engraving Machine for door glass

Why choose us

1. We’re manufacturer, which have specialized in the line for many years.

2. We could pick you up to visit our factory,

3. Best after-sale service.

4. Competitive price, high quality and quick delivery for long business.
