ISO 1523 IP 170 Pensky Martin Flash Point Apparatus

ISO 1523 IP 170 Pensky Martin Flash Point Apparatus thumbnail-1
ISO 1523 IP 170 Pensky Martin Flash Point Apparatus photo-1
US$ 1 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
friend instrument
Model Number:
FDT-0234
Contact Supplier Request Quote Chat Now
Changsha Friend Experimental Analysis Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hunan, China
Brand Name friend instrument
Model Number FDT-0234
Power Electronic
Usage Auto Testing Machine



Fully automatic closed flash point tester cryogenic FDT-0233







Application range



Conforms to standard GB/T261-83 and ISO2719-1988   ASTM D93   standard requirements.







Features



1, color LCD touch-screen operator interface is friendly



2, The instrument also has a failure since Jane functionality, failure automatically prompt function



3, The instrument has to heat up automatic control, automatically opening The lid and ignition, automatic printout, automatic cooling, The machine automatically complete The barometric pressure correction and automatically display The flash point temperature, built-in micro-thermal printer automatically report The test results



The 4, USB/232 communications interface to communicate with The host computer, easy to form a centralized management system



5, German imports of stainless steel temperature sensor detects The temperature data is accurate and reliable



Mechanical moving parts servo drive timing belt drive, work without gaps, low noise, reliable and difficult to damage, no lubrication maintenance.



7, simply set The expected flash point instrument in strict accordance with The standard automatic test, The end of The test automatically print test results, and tone. Without judgment and does not depend on The proficiency of The operator.



8, thermocouple detection flash point of High sensitivity detection of accurate, durable and easy to maintain.



9, sample box The thermal compound thermostat with built-in refrigeration heating andGerman imports Dan whisk Adams compressor, thermostat reliable lag, not easily damaged







Specifications



1,Environment: Temperature 0 ~ 60° C; Relative humidity: 80%



2: 7-inch color LCD touch screen.



3, The Heating rate: less than 50 ° C; 1° C; / min, Higher than 50 ° C; for 2-3 ° C; / min



4, Measuring range: -30 to +80° C Accuracy ± 1° C;



5,Temperature components: PT100 stainless steel temperature sensor



6, The lifting arm: automatically raised or lowered



7, ignition: gas flame ignition



8, detection: automatically detects flash fire and automatically print The experimental data.



9, Communication: USB/232, communication interface.



10, The cooling system: compressor cooling



11, Print: You can print this or any print stored 100 experimental results

12, Power AC220V 50Hz, total power: 1.5 kw”                               ISO 1523 IP 170 pensky martin flash point apparatus







FAQ
Payment & Shipping Terms
Supply Capacity
Payment term :
T/T or L/C
Production capacity :
100pcs/month
MOQ:
1 pc
Packing :
 Wooden case
Price
negotiable
Delivery way
 By Air
Means of transport :
FOB , CIF , CFR
Delivery time :
10 days

    12 months warranty



flash point related

ISO 1523 IP 170 pensky martin flash point apparatusISO 1523 IP 170 pensky martin flash point apparatusISO 1523 IP 170 pensky martin flash point apparatus ISO 1523 IP 170 pensky martin flash point apparatusISO 1523 IP 170 pensky martin flash point apparatus ISO 1523 IP 170 pensky martin flash point apparatus

Model

FDT-0281



FDT-0231



FDT-0232



FDT-0272



FDT-0233



FDT-0234



Standard

ASTM D6450,D7094, SH/T 0768-2005



GB/T261   ASTM D93   ISO 2719



GB/T261-2008     ASTM D93 ISO 2720



GB/T261-2008   ASTM D93 ISO 2719



GB/T261  ASTM D93   ISO 2719



GB/T 5208,ISO 1523,ISO 3679



Range

ambient~30°C

10-40℃

10-40℃

ambient~300℃

-30 ~ +80℃

-30~50℃

Repeatability

≤2°C

≤2°C

≤2°C

≤2°C

≤2°C

≤4°C

Reproductively

≤4°C

≤4°C

≤4°C

≤4°C

Automatic up/down

Y

Y

Y

Y

Y

Y

With micro printer

Y

Y

Y

Y

Y

Y

Display

N

N

Y

Y

Y

Y

Communication port

Y

Y

Y

Y



Y



Y

Sample

1ml

Standard oil cup

Standard oil cup

Standard oil cup

Standard oil cup

Standard oil cup
