Help CenterAutomatic Closed Cup Flash Point Lab Instrument
Related Products
-
China Supplier of Crude Oil Flash and Ignition Point Testing Instrument Quality ChoiceUS$ 200 - 10,000MOQ: 1 Set -
Engine Oil Automatic Closed Cup Flash Point TesterUS$ 1 - 1,000MOQ: 1 Set
-
Astmd 92 Gear Oil Automatic Flash Point TesterUS$ 1 - 1,000MOQ: 1 Set
-
Astmd 92 Turbine Oil Abels Flash Point ApparatusUS$ 3,000 - 4,600MOQ: 1 Set
-
Petroleum Products Flash Point ApparatusUS$ 3,000 - 4,600MOQ: 1 Set
Specifications
China manufacturer.1. automatic equipment
2.easy to operate and maintainace
3.high precision
4.HOT SALE
Scope
Automatic Flash Point Tester is based on GB / T261 standard "flash point of petroleum products Determination (closed cup)" provides design and manufacture. LCD screen full Chinese interactive interface, menu-oriented input, advanced technology, high technology is an ideal alternative to imported products. Products in the domestic leading level.
Features
1, in line with GB / T 261-2008 standard, with different types of samples A, B two experimental procedure to choose from;
2, innovative introduction of imported XECOM US data processing chip, fast and accurate data processing;
3, the instrument has a self-diagnostic function, the instrument prompts automatic fault;
4, the instrument has self over-temperature protection, over-temperature range can be arbitrarily set;
5, color LCD, real-time simulation trace display function curves warming and test time, the user interface in real-time prompts;
Technical Parameters
1 Power supply: AC 220V ± 10%, 50Hz
2, range: room temperature ~ 300 ℃;
3. Repeatability: ≤2 ℃ reproducibility: ≤4 ℃
4, the detection unit: 3 cups
5, the resolution of: 0.1 ℃
6. Accuracy: 0.5 ℃
7, heating rate: meet the GB / T261-2008 standard
8. Ignition: electronic ignition, the gas flame
9, adapt to the environment temperature: 10-40 ℃
10, to adapt to the ambient humidity: <85%
11 Power consumption: less than 300W
| Packaging Detail: | standard wooden case |
| Delivery Detail: | 10 working days after receipt of the advance payment. |
warranty: 12 month
Friend has always adhere to the alliance strategies with customer unit development, and integrate enterprise resource advantages,with the pursuit of excellence in product quality, innovative and pragmatic attitude to customer needs and to provide professional pre-sales,
after-sales service.
welcome to our factory !
Since the establish of Friend,it uphold the Western industrial civilization "artisan spirit" as the ideas, and constantly improve our products, and continuously improveour processes to meet market demand, and strive to create a new management models and new products to meet customer growing needs.
open cup flash point series |
|
|
|
||
Model |
FDT-0101 |
FDT-0131 |
FDT-0132 |
FDT-0172 |
FDT-0192 |
Standards |
ISO2592,ASTM D92 |
||||
Range |
ambient~360℃ |
ambient~400℃ |
ambient~400℃ |
ambient~400℃ |
ambient~400℃ |
Repeatability |
≤4℃ |
≤4℃ |
≤4℃ |
≤4℃ |
≤4℃ |
Reproducibility |
≤6℃ |
≤6℃ |
≤6℃ |
≤6℃ |
≤6℃ |
Automatic up/down |
N |
Y |
Y |
Y |
Y |
Display |
N |
BlueScreen |
Color screen |
||
Automatic detect |
N |
Y |
Y |
Y |
Y |
Detect Fire point |
N |
N |
Y |
N |
N |
with microprinter |
N |
Y |
Y |
Y |
Y |
Sample cup |
1 |
1 |
1 |
3 |
6 |
Ignition source |
gas |
Electronic ignition,gas flame |
|||
learn more(click--) |
FDT-0101 |
FDT-0131 |
FDT-0132 |
|
|
|
|
|
|
|
|
Pensky-Martens Closed Tester |
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|||||||||
Model(Click-----) |
FDT-0201 |
FDT-0231 |
FDT-0232 |
FDT-0233 |
FDT-0272 |
FDT-0234 |
FDT-0281 |
|||||||||
standards |
GB/T261 ASTM D93 ISO 2719 |
GB/T 5208,ISO 1523,ISO 3679 |
ASTM D6450,D7094, SH/T 0768-2005 |
|||||||||||||
Range |
ambient~250℃ |
ambient~300℃ |
-30 ~ +80℃ |
ambient~300℃ |
-30~50℃ |
ambient~300℃ |
||||||||||
Repeatability |
|
≤2℃ |
≤2℃ |
≤2℃ |
≤2℃ |
|
≤2℃ |
|||||||||
Reproducibility |
|
≤4℃ |
≤4℃ |
≤4℃ |
≤4℃ |
|
≤4℃ |
|||||||||
Automatic up/down |
|
Y |
Y |
Y |
Y |
|
Y |
|||||||||
Display |
|
Blue Screen |
Color screen |
Color screen |
Color screen |
|
Color screen |
|||||||||
Automatic detect |
|
Y |
Y |
Y |
Y |
|
Y |
|||||||||
Detect ignition |
|
Y |
Y |
Y |
Y |
|
Y |
|||||||||
Ignition source |
|
Electronic ignition,gas flame |
|
Arc ignition |
||||||||||||
Small sample |
|
N |
N |
N |
N |
|
1-2ml |
|||||||||
Sample cup |
|
1 |
1 |
1 |
3 |
|
1 |
|||||||||
1. What's the warranty?
Normally 12 months
2.Does the power supply can customized?
YES ,if you need customized power supply,pls tell us when you put the order.
3.What's the production time?
Usually 20 days for production, some equipments need extra time to debug.
4.What's the Dlivery method ?
Light-weight cargo is usually by express , Air transport and sea shipping is acceptable (provide with safty packing)
5.What's the delivery time?
According to different method and country , express will be 6~15 days
6. How to install and operate?
According to each instruction manual which sent with equipment. ( We also provide after-sale technical support)
7.What's the payment term?
Usually we do 30%TT deposit ,70%TT balance before shipping.LC,Western Union,MoneyGram are acceptable.
