Help CenterSeamless Line Pipe
Related Products
seamless line pipe
API 5L line pipe
Features:
OD: 42-356mm
WT: 3.5-40mm
Material: GrB X42 X52 X56 X60 X70 X80
Length: =<12m
Surface:varnishing or black painting
Marking: As per customer's requirement
packing:
Hexagonal shape bundles wrapped with strong steel trip or wooden carton packing or according to customers' requests
Usage:
Used for conveying gas, water and petroleum
api 5l x42 steel line pipe
Line pipe
Standard API 5L
Application
For gas, water and oil conveying in petroleum and natual gas industies
Mechanical Properties:
Standard |
Grade |
Yiled strength
|
Tensile strength |
elongation |
Impact energy |
||
API 5L |
Min |
Max |
Min |
Max |
See table 3 of API 5L |
Min |
|
B |
241 |
448 |
414 |
758 |
41(27) |
||
X42 |
290 |
496 |
414 |
758 |
41(27) |
||
X46 |
317 |
524 |
434 |
758 |
41(27) |
||
X52 |
359 |
531 |
455 |
758 |
41(27) |
||
X56 |
386 |
544 |
490 |
758 |
41(27) |
||
X60 |
414 |
565 |
517 |
758 |
41(27) |
||
X65 |
448 |
600 |
531 |
758 |
41(27) |
||
X70 |
483 |
621 |
565 |
758 |
41(27) |
||
Notes: Impact requirements in transverse direction are shown in brackets
Dimension Tolerance:
Standard |
O.D Tolerance |
W.T Tolerances |
|
API SPEC 5L |
D<60.3 |
+0.41mm,-0.40mm |
+15% -12.5% |
D>=60.3 |
+0.75%,-0.40mm |
||
Contact person: Charlene
