Factory Prices 30KVA Kubota diesel generator price
Genset Specifications:
Compose of KUBOTA engine and Stamford alternator. China stamford alternator optional.
Prime Power |
20KW/25KVA |
Standby Power |
22KW/27.5KVA |
Rated Speed |
1500RPM |
Output Frequency |
50HZ |
Phase |
3 |
Rated Voltage |
400V |
Engine Model |
V2003-T |
Alternator Model |
PI144E |
Fuel Consumption of 100% load |
6.86L/H |
Fuel Consumption of 75% load |
5.12L/H |
Voltage Regulation Rate |
≤±1% |
Random Voltage Rate |
≤±1% |
Frequency Regulation Rate |
≤±5% |
Random Frequency Variation |
≤±0.5% |
Dimension (open type) |
1750×750×1200(mm) |
Weight (open type) |
680kg |
Dimension(silent type) |
2000×850×1350(mm) |
Weight (silent type) |
900kg |
Engine Specifications:
Kubota Diesel Engine
Engine Model |
V2003-T |
Number of Cylinder |
4 |
Cylinder arrangement |
Vertical in-line |
Cycle |
Four Stroke |
Aspiration |
Natural aspirated |
Bore×Stroke (mm×mm) |
98×110 |
Displacement |
3.318L |
Compression Ratio |
23.0:1 |
Prime Power/Speed(KW/rpm) |
26.3/1500 |
Standby Power/Speed(KW/rpm) |
28.9/1500 |
Speed Governor |
Electric |
Cooling System |
Water-cooled, 4℃ Radiator As Standard, 50℃ Is Optional |
Speed Stability(%) |
≤5% |
Total Lubrication System Capacity (L) |
13.2 |
Coolant Capacity(without radiator) (L) |
8.2 |
Fuel Consumption at 100% Load(L/Hr) |
6.86(at 1500RPM) |
Starter Motor |
DC12V |
Alternator |
AC12V |
Alternator Specifications:
Alternator Model |
PI 144E |
Alternator Brand |
Stamford |
Exciter Type |
Brushless, Self-excited |
Rated Output |
20kw/25kva |
Rated Speed |
1500RPM |
Rated Frequency |
50HZ |
Phase |
Three |
Rated Voltage |
230V/400V (Available with customer requirements) |
Power Factor |
0.8 |
Voltage Adjust Range |
≥5% |
Voltage Regulation NL-FL |
≤±1% |
Insulation Grade |
H |
Protection Grade |
IP23 |
Features:
Low consumption and low noise
Powerful load capacity.
AMF/ATS
1 year warranty
Base fuel tank
Open typr or Silent type
Our work shop
Payment;
30% deposit(T/T),balance (70%) to be paid before shipment.(for bulk cargo)
30% deposit(T/T),balance (70%) to be paid after receipt of the B/L copy.(For container order)
L/C at sight. (For container order)
Warranty
A guarantee of 1200 hours or 12 months from date of commissioning or 18 months from shipping, whichever occurs first, is provided. Warranty will be invalid if customer disobey the requirements of the operation and maintance in Generator Set Technical Manual.This is supported by the added operation and maintenance backing of the principal component manufacture, global service networks.
Fujian Jinlong Electrical Machinery Group Co., Ltd (JINLONG GROUP for short) was established in 1994 JINLONG Group regards electromechanical industry as the core, and involves International Trade, Finance, Investment E.T.C. After years of unremitting efforts, our company has developed into a certain scale of comprehensive, international group co., LTD.
Have passed ISO 9001:2008, CE, GS Certificate e.t.c.. Brand “Jinlong” is “FUJIAN PROVINCE FAMOUS TRADEMARK” & “FUJIAN PROVINCE FAMOUS BRAND PRODUCTS” that is recognised by international customers. Products are sold in European, South America,South-East Asia, Middle East, Africa e.c.t over 80 countries and areas. Favored by the majority of customers.
