Help CenterPlica Tube Connector
US$ 1 - 5
MOQ: 500 Boxes
Key Specifications
Get Latest Price
Material:
Alloy
Technics:
Casting
Type:
Elbow
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1/2 Inch Emt Set Screw Conduit ConnectorUS$ 1.5 - 3MOQ: 500 Boxes -
EMT Zinc Die Casting ConnectorUS$ 2 - 3MOQ: 500 Boxes
-
LIQUID TIGHT CONNECTOR-90degUS$ 1.5 - 2MOQ: 500 Boxes
-
9pcs Tools Sets, Household Tool Set, Tools, Tools SetsUS$ 15 - 30MOQ: 1000 Sets
-
11pcs Household Tools, Household Tools Sets, Tool, ToolsUS$ 15 - 30MOQ: 1000 Sets
Material
Alloy
Technics
Casting
Type
Elbow
Place of Origin
Shanghai, China
Model Number
VKC
Brand Name
gaohe
Connection
Female
Shape
Other, Square
Head Code
Square
Product material:Galvanized Alloy
Property:
1.Special design fited for the connection of PIK metal and BG, VKC, KS and KG fitting.
2.Water resistant, dust resistant, inactive with salts, acids, alkalis, alcohols, oils and greases as well as general dissolvent.
How to use:
Union for Plica Tube Fitting (VKC) can be connected with no-screw thread pipe, PIK metal connector or steel pipe with screw thread, making assembly easy and time-saving, promising strong pull resistance.
Besides the following specifications, the size and thread standard can be varied at your discretion as per requirements.
| Specification | PIK Type Metal Pipe | BG,VKC,KS and KG Connector | ||||
| Internal diameter (mm) | External Diameter (mm) | Length of Each Coil (m) | Pitch of Thread(mm) | Screw Thread | Steel | |
| 12# | 11.4 | 16.1 | 50 | 1.6 | G1/2″ | 1/2″ |
| 15# | 14.1 | 19.0 | 50 | 1.6 | G1/2″ | 1/2″ |
| 17# | 16.6 | 21.5 | 50 | 1.6 | G1/2″ | 1/2″ |
| 24# | 23.8 | 28.8 | 25 | 1.6 | G3/4″ | 3/4″ |
| 30# | 29.3 | 34.9 | 25 | 1.8 | G1″ | 1″ |
| 38# | 37.1 | 42.9 | 25 | 1.8 | G1/1/4″ | 1/1/4″ |
| 50# | 49.1 | 54.9 | 25 | 1.8 | G1/1/2″ | 1/1/2″ |
| 63# | 62.6 | 69.1 | 10 | 2.0 | G2″ | 2″ |
| 76# | 76.0 | 82.9 | 10 | 2.0 | G2/1/2″ | 2/1/2″ |
| 83# | 81.0 | 88.1 | 10 | 2.0 | G3″ | 3″ |
| 101# | 100.2 | 107.3 | 5 | 2.0 | G3/1/2″ | 3/1/2″ |
Model: VKC
Productivity: 50,000pcs/year
Origin: Shanghai,China
Packing: Cartons or Plastic Bags
Min. Order: 500pcs
