Metal cutting flame torch cutting machine
flame and plasma cutting
Machine feature
1. The quantity of plasma torch and flame torch can be adjust according to customer’s requirement.
2, CNC flame / plasma cutting machine is a high efficiency, energy saving cutting equipment. Suitable for various thickness of carbon steel, stainless steel and nonferrous metal precision sheet metal cutting stock, raise plate utilization, saving time and material. CNC flame cutting machine for carbon steel 5-300mm thickness of high-quality.
3, Gantry box beams, carrying capacity, suitable for a wide span, efficient bilateral drive, compact structure, the overall tempering, fully eliminate welding stress, stable and reliable performance.
4, the transverse rails using domestic or imported linear guide rail, high accuracy, good guide. Vertical guide rail using characteristics, the surface grinding process, with high mechanical precision and wear resistance.
5, the driving rack gear customized by professional manufacturers, carburizing hardening, high accuracy. Horizontal, vertical transmission from Germany NEUGART high-precision, high torque, low backlash planetary gear reducer maintenance-free.
6, Japanese Panasonic AC servo drive or stepper motor drive make sure the machine run more smoothly, speed gear wider range, acceleration time is short.
7, automatic programming system to make NC programming is no longer complex, easy;
8, control control system uses currently the most excellent stability and superior anti-jamming capability.
9, the system control panel is divided into a gas distribution system and gas path, With automatic ignition device, tempering prevention device, security and stability.
10, according to user needs can be equipped with a variety of imported or domestic plasma cutter, to meet the requirement of different metal material cutting.
11, according to user needs, can increase other special features.
Technical parameter
Rail gauge(mm) |
3000 |
4000 |
5000 |
6000 |
7000 |
Effective cutting width (mm) |
2200 |
3200 |
4200 |
5200 |
6200 |
Effective cutting length(mm) |
Can produce according to user’s requirement |
||||
Control system |
STARFIRE Or SJTU |
||||
flame torch |
Professional flame cutting torch |
||||
Plasma cutter |
Can equip according user’s requirement |
||||
Torch travel height(mm) |
200 |
||||
Traveling speed (m/min) |
0-10000 |
||||
Cutting speed(mm/min) |
0-6000 |
||||
Flame cutting thickness(mm) |
5-300 |
||||
Plasma cutting thickness(mm) |
Depends on plasma cutter |
||||
Flame |
Acetylene or propane |
||||
foundation |
H steel or cement |
||||
Machine Photo
Sample photo
