cold-pressed oil extraction machine
- Automaitc multifunction screw oil extraction machine
“ALL IN ONE PIECE “integrated oil press machine for you to obtain virgin seed oil
* The detail description of the cold-pressed oil extraction machine :
- It cold-pressed oil extraction machine extract vegetable oil from various kinds of oil materials, soybean, sunflower seeds, peanut, sesame,coconut,rapeseeds, Cotton seed, cashew, hemp seed, palm, walnuts and all the oil content crops.
- It has multiple functions, including screwing oil press, electrical element for heating chamber, vacuum filter for clearing oil .
- Before pressing some parts of the press such as the press chamber, press screw and press ring will be pre-heated. During pressing, the press can filter the oil in due time. Only one machine the user could get the better edible oil
- After pressing and filtering, we can get pure oil from materials.
- It can save labor and save cost : only 1 or 2people can finish the production. Small land using: only 10-20 square meters can meet the need of production.
- The oil left in cake from oil extraction machine is less than 6% . And cake thickness can be adjusted once the machine stop running.
* Main part of the cold-pressed oil extraction machine :
1. Screw oil extraction machine
2. Electrical element for heating chamber of oil extraction machine.
3. Vacuum filter of oil extraction machinefor clean crude oil
4. Squeezing bolt of oil extraction machine
5. Heating ring of oil extraction machine
* Highlighted features of the cold-pressed oil extraction machine :
1. The main part is made of stainless steel and alloy steel.
2. Elegant appearance structure,pure oil meet with the standard of health quarantine.
3. high degree of automation.
4. Adopt automatic circuit controlling and automatic temperature controlling.
The different models of the cold-pressed oil extraction machine
Model |
Capacity (T/D 24 hours) |
Power (KW) |
Outside Size(MM) |
Weight(KG) |
AMS-68 |
1-1.5 |
5.5 |
900*530*760 |
160 |
AMS-80 |
2-3 |
5.5 |
1810*560*735 |
370 |
AMS-100 |
3-5 |
7.5 |
1910*610*765 |
480 |
AMS-120 |
5-6 |
11 |
2060*610*760 |
650 |
AMS-120C |
7-8 |
15 |
2100*700* 770 |
650 |
AMS-130 |
9-12 |
18.5 |
2280*700* 770 |
850 |
AMS-160 |
13-18 |
22 |
2400*700* 780 |
1050 |
The spare parts of the cold-pressed oil extraction machine:
Our production workshop of the cold-pressed oil extraction machine :
The packing and delivery of the cold-pressed oil extraction machine:
Other types of the oil press machine for your reference:
2. Automatic hemp oil extraction machine The Automatic Oil press Equipped with automatic temperature-controlling and oil-filtering device, automatic screw oil press is more efficient and labor-saving.
Model |
Capacity (T/D 24 hours) |
Power(Kw) |
Outside Size(mm) |
Weight(kg) |
AMS-68A |
1-1.5 |
5.5 |
1600*890*1500 |
370 |
AMS-80A |
2-3 |
5.5 |
1760*1050*1850 |
600 |
AMS--95A |
3-5 |
7.5 |
2050*1050*1850 |
940 |
AMS--120A |
4-6 |
11 |
2220*1050*1850 |
1200 |
AMS--120CA |
6-8 |
15 |
2340*1050*1850 |
1300 |
AMS--130A |
9-12 |
18.5 |
2450*1100*1950 |
1500 |
AMS--160A |
13-18 |
22 |
2600*1200*1950 |
1680 |
