Seed oil extraction machine
Materials of the seed oil extraction machine:
The seed oil extraction machine can be used to extract vegetable oil by continuously pressing
peanuts, rapeseeds, soybeans, castor oil plant, sesame seeds, benne seeds, palm seeds, sunflower seeds, cotton seeds, tea seeds, tung seeds and etc.
Specification of the seed oil extraction machine:
- Fully automatic hydraulic oil press,simple,convenient,energy saving,competitive price.
- This oil press machine is composed of feeder, gearbox, pressing cage, screw shaft and machine stand etc
- final oil is high quality, good smell, and high yield rate.
- It uses high carbon steel, which through high frequency quenching and heat-resisting, it is high hardness and strength, good abrasion resistance that suit for high temperature and high pressure continous working, all this had improved the service life of the oil press for decades.
Model |
Capacity (T/D 24 hours) |
Power (KW) |
Outside Size(MM) |
Weight(KG) |
AMS-68 |
1-1.5 |
5.5 |
900*530*760 |
160 |
AMS-80 |
2-3 |
5.5 |
1810*560*735 |
370 |
AMS-95/100 |
3-5 |
7.5 |
1910*610*765 |
480 |
AMS-120 |
5-6 |
11 |
2060*610*760 |
650 |
AMS-120C |
7-8 |
15 |
2100*700* 770 |
650 |
AMS-130 |
9-12 |
18.5 |
2280*700* 770 |
850 |
AMS-160 |
13-18 |
22 |
2400*700* 780 |
1050 |
3. The Structure of the seed Oil Extraction Machine,
Screw oil press is a popular type of the Seed oil extraction machine , mainly composed of feeder, gearbox, pressing chamber and oil receiver. Some screw oil press machines are equipped with electric motors as required. Pressing chamber is the key part which contains a pressing cage and a screw shaft rotating in the cage. An electric cabinet is also necessary to control the whole working procedure.
4. The picture of the Seed Oil Extraction Machine,
The spare parts of the Seed oil extraction machine
The complete processing of the Seed oil extraction machine
