2013 Automatic Pellet packing machine
1. Pellet Packing Machine
Application: apply to adapt packaging bags, Sacks Bags, bags and plastic bags.
Material: the material contact part adopts 304 stainless steel, high corrosion resistance.
Applicable materials: particles, powder materials, mixing materials, Widely used in feed, compound fertilizer, BB fertilizer, grain, seed, chemical industry etc..
Special design of the feeding and metering mechanism, improve the material flow speed, fast packing speed, high accuracy of packing.
Quantitative range, high precision, with the conveyor table lifting sewing machine, one machine with multifunction, high efficiency.
Imported sensor, pneumatic actuator, reliable work, simple maintenance.
2. Pellet Packing Machine
a).PLC Controlling screen.
b)the host machine adopts inverter, rapid speed to control material flowing, slow speed to control accurate measuring.
c).It can save shift output, day output and accumulative output automatically.
d).se infrared rays to transfer, servo feeding, save more energy.
e)Technical Data
Model: DSC-A25-3
Packing speed: 2- 4 bags per minute Weighing scope: 15-50kgs per bag
Tolerance: ±50g Control method: PLC
Supply voltage: AC 380V Power of main engine: 1.1KW
Gas supply: instrument air without oil or dust
Pressure: 0.4—0.6Mpa Gas consumption: 0.4N m3/min
3. Pellet Packing Machine
