Thermal Shrink Packaging Machine

Thermal Shrink Packaging Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Machinery & Hardware
Packaging Type Cartons
Packaging Material Plastic
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 380V
Power 5kw, 8.8kw
Place of Origin Henan, China
Brand Name AMISY
Model Number AMS-SW
Dimension(L*W*H) 1200x650x840mm
Weight 92KG
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Thermal Shrink Wrapping Machine



Introduction:

This series machines adopt quartz far-infrared tubes as heating source, electronic non step variation, automatic temperate regulation, solid rely control, stable and reliable, low noise and long duration. The packed product can prevent from getting damp and protect against knock. It is suitable for tight wrapping packing of many-pieces articles and tray packing.



 Usage:

  • It has full-auto characteristics,such as conveying materials,ordering bottles,wrapping film,shrinking,cooling and shaping and others.
  • It adopts advanced film thermal sealing technology.The seal seam is clear,firmer and more beautiful.
  • Conveying film adopts induced switch control,adjust the conveying film length relibaly and reduce consumption.
  • The conveying motor adopts imported frequency converter control.Its conveying is smooth and the stepless govern is carried out.
  • It adopts advanced screw air supplying circulating structure and 3-layer insulating treatment .The wrapping is firm and save energy.
  • Strengthening type cooling shaping channel make the package film form high-strength state and the transportation and storge is conveninent.

 Technical parameter:

Model

AMS-SW-450A

AMS-SW-400A(stand model)

Power Supply

110/220/380V 50-60Hz

110/220/380V 50-60Hz

Power Consumption

8.4Kw

8.4Kw

Work Speed

0-10m/min

0-10m/min

Conveying Weight

10Kg

10Kg

Size of Shrink Oven

800x450x250mm

800x450x250mm

Machine Size

1200x650x780mm

1200x650x840mm

Machine Weight

88Kg

92Kg



Thermal shrink packaging machine
