Amisy! NZ-03 industrial wall mounted combustible/flammable gas leak detector/alarm 0086 15037127860

Measuring gas

combustible/flammable gas

Measuring range

0-100%LEL

Resolution

1ppm

Sensor Principle

catalytic combustion

Accuracy

±3%F.S

Response time

≤30 s

Temperature range

-20 - +50°C

Humidity range

15% - 95% RH (non-condensing)

Output signal

International standard 4-20mA signal can be directly access

to the plant DCS system(Users can choice)

Transmission cable

Two-core shielded cable ( three cores shielded cable for

combustible gas section:2×1.5mm2,external diameter <10mm

Transmission Distance

≤1000m

Working Voltage

AC220V

Alarm point

First level alarm point25%LEL

two-level alarm point50%LEL

(Users can set the alarm point by theirselves)

Alarm output

Relay Output, Capacity AC 220V 2A

Display Mode

LED nixie tube display(you can select LCD)

Dimension

327mm(L)x 150mm(W)x75mm(H)

Instrument net weight

1.5Kg

Instrument case

Die-casting aluminum

Service entrance

stainless steel explosion-proof and water-proof connect (Lock diameter 8mm )

Mounting means

Wall mount

Explosion-proof grade

Exd IICT6 ( explosion-proof applications ) ; ExiaIICT4

Protection grade

IP66
