Home > Products > Fertilizer Equipment& Fertilizer production line > organic fertilizer Disc Granulator
organic fertilizer Disc Granulator
- 100 Set / Sets per Month
- Qingdao Tianjin Shanghai
- T/T Credit Card PayPal
- organic fertilizer production line
- machine for making organic fertilizer
- Chicken Manure Drying and Organic Fertilizer Making Machine for Poultry Farming
- Organic Fertilizer Making Machine For Poultry Manure
- Organic fertilizer production line
- Low Temperature Granule Making Organic Ball Fertilizer Granulation Machine
Product Details
Condition: | New | Product Type: | Fertilizer | Place of Origin: | Henan, China |
Brand Name: | Amisy | Model Number: | YPZL | Voltage: | 380v |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Disc Fertilizer Granulating Machine
Disc Fertilizer Granulating Machine Advantages
*Arc structure ensures high granulating rate of 93%.
*Novel and rational structure,light weight. Flexible granulating positon.
*Adjustable angle of large discs because of the pads.
*Unique unpowered knives lowers down power consumption.
*Large discs consists of disc body and disc joints. The disc joints can be accomodated upwards and downwards.
*New dregging disign and good granulating effects. Uniform granulators and most of the particles’ diameter is 3-5mm.
What’s the Diameter of Organic Fertilizer Particles?
It is the fertilizer capacity that mostly influences the diameter of disc granulating machine.The fertilizer equipment producing capacity and organic fertilizer producing requirements also matters a lot. When the diameter is determined, the height can be also calculated. In general,the larger of the diameter, the higher of the height. The height of discs plays important role in granulating time.
Disc Fertilizer Granulating Machine Technical Data
Type | Inner Disc | Disk Side | Volume | Rotation | Motor | Capacity |
ZL25 | 2500mm | 500mm | 2.5m³ | 13.6r/min | 7.5kw | 1-1.5T/H |
ZL28 | 2800mm | 600mm | 2.7m³ | 13.6r/min | 11kw | 1-2.5T/H |
ZL30 | 3000mm | 600mm | 4.2m³ | 13.6r/min | 11kw | 2-3T/H |
ZL32 | 3200mm | 600mm | 4.8m³ | 13.6r/min | 11kw | 2-3.5T/H |
ZL36 | 3600mm | 600mm | 6.1m³ | 11.3r/min | 15kw | 3-5T/H |
Reference pictures of Bio-organice Fertilizer Disk granulating machine
1.Recommend suitable machines with solution,according to customer's requirements.
2.Provide two year of free warranty for fertilizer production line from the delivery date.
3.Provide worker training for fertilizer production line,24hours after sale-service by email.
4.Technician go to abroad for guide installation&production is also available.
5.Supply Bio-organic Fertilizer production line:output round shape granule
6.Capacity from 5000Tons/Year to 100000Tons/Year for option.
Pls kindly provide the information when you send inquiry:
1.What's your raw material?
2.How large capacity do you need?
